Garden multi-row

;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;
;;                                                                                                           ;;
;;                                             OVERVIEW OF TERMS                                             ;;
;;                                                                                                           ;;
;;   In this model, the 'breeds' or AGENTS are the things you see within the garden interface that can move, ;;
;;     change size, appear, or dissapear.                                                                    ;;
;;   The breeds are collectively called TURTLES, and most of them are living things.                         ;;
;;   The code tells you what to call them in plural or singular terms.                                       ;;
;;   PATCHES are the background squares of the model, in this case, they represent the soil of the garden.   ;;
;;   GLOBALS are variables in the model that are determined by buttons or actions on the interface.          ;;
;;                                                                                                           ;;
;;   Together these three items (TURTLES, PATCHES, GLOBALS) make up all that is defined by the model.        ;;
;;   Everything else in the code defines the PROCEDURES that define the rules of the model                   ;;
;;   PROCEDURES come after the word "to" and are followed by "end"                                           ;;
;;   Some procedures might be defined on the interface page (inside a button) as opposed to the code         ;;
;;                                                                                                           ;;
;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;

breed [farmers farmer]
breed [plants1 plant1]
breed [plants2 plant2]
breed [weeds weed]
breed [drops drop]
breed [fungi fungus]
breed [bees bee]

turtles-own [
  energy            ; the life force of the creatures
  my-heading        ; which direction it is facing
  ]

patches-own [       ; Each patch of soil has these qualities.
  nutrients         ; determines the soil quality
  hydration         ; how much water is in the soil
  ]

globals [
total-harvested     ; The total pounds of produce harvested by the farmer
money               ; Starts off as your initial budget, and is updated based on the actions you take as the farmer.
crop                ; When plants are harvested, they are then called crop.
pesticide-ppm       ; Pesticide ppm = parts per million. This number increases when you add herbicide
]

to setup            ; The actions that happen when you press the setup button
  clear-all
  setup-patches
  setup-turtles
  make-farmer
  reset-ticks
  set money (budget - ((count plants1) + (count plants2)) * plant-cost)
end

to setup-patches
  ask patches [
 set nutrients (random 15)         ; Each patch has a random amount of nutrients between 1 and 15 at first
   set hydration (random 10)]      ; Each patch has a random amount of hydration between 1 and 10 at first
  repeat 5 [diffuse nutrients 1]   ; The diffuse command 'smoothes out' the random numbers, so that a patch with 15 isn't next to a patch with 1
  repeat 2 [diffuse hydration 1]
  ask patches [
   set pcolor scale-color brown nutrients  10 0   ; How dark or light brown the patches are relates to the level of nutrients
  ]
end

to setup-turtles
  create-weeds 0
  create-drops 0
  create-fungi 0
  create-bees 0
end

to make-farmer
  create-farmers 1 [
    set color cyan             ; Change colors using the color swatch (see 'tips and tricks' sheet)
    set size 3                 ; Change size
    set shape "farmer"         ; You can find more possible shapes online (http://ccl.northwestern.edu/netlogo/docs/shapes.html)
    setxy 0 0
    set heading 90
    set my-heading 270
    run "seed-1"
    run "seed-2"
  ]
end

to seed-1                           ; This procedure sets up all of the first variety of plant
  repeat (num-plants-1)
[
 ask farmers [
  (ask patch-here [
      if not any? plants1-here [    ; No two crops can grow in the same space
        sprout-plants1 1 [
          set shape "plant small"
          set size 0.3
          set color 55
          set energy 2
        ]]])
  fd (spacing-1)
  if not can-move? spacing-1 [
    set heading 0
    fd spacing-1
    set heading my-heading
    ifelse my-heading = 90 [set my-heading 270] [set my-heading 90]
  ]]]
end

to seed-2                           ; This procedure sets up the second variety of plant
  setxy 0 4                         ; They start planting at coordinate (0, 4) in the field (top half)
  set heading 90
  set my-heading 270
  repeat (num-plants-2)
[
 ask farmers [
  (ask patch-here [
      if not any? plants2-here [
        sprout-plants2 1 [
          set shape "plant small2"  ; The shape, size, and color of plant2 are different from plant1
          set size 0.2
          set color 68
          set energy 2
        ]]])
  fd (spacing-2)
  if not can-move? spacing-2 [
    set heading 0
    fd spacing-2
    set heading my-heading
    ifelse my-heading = 90 [set my-heading 270] [set my-heading 90]
  ]]]
end

to re-seed                         ; How you re-plant once the model is running
run "seed-1"
run "seed-2"
set money (money - ((count plants1) + (count plants2)) * plant-cost)
end

to go
      animate               ; The main sequence of procedures for the garden to grow
      harvest-plants        ; This + harvest-weeds define actions you take with the mouse
      harvest-weeds
       tick
end

to animate                                                     ; Happens every 'tick' while the model is running
 if drought [ask patches [set hydration (hydration - 0.1)]]    ; This will happen constantly in drought mode
 if flood [ask patches [set hydration (hydration + 0.2)]]      ; This will happen constantly in flood mode
 ask turtles [                                                 ; All turtles run through these procedures
   run word breed "-grow"
   run word breed "-check-if-dead"
   run word breed "-eat" ]


 if any? patches with [                                 ; Conditions that would enable weeds to grow
   not any? plants1-here and
   not any? plants2-here and
   nutrients > 5 and                                    ; Weeds are more likely to appear in spaces with high nutrient levels
   hydration > 2]
 [
   ask one-of patches with [                            ; The growth is random to one of those patches
     not any? plants1-here and
     not any? plants2-here and
     nutrients > 5 and
     hydration > 2]
   [
    sprout-weeds 1
    [
      set breed weeds
      set shape "flower budding"
      set color lime
      set energy 1
      set size 0.03
    ]


if (count (patches with [any? plants1-here with [size > 3.5]]) > 5)     ; Conditions that determine if bees show up
  or (count (patches with [any? plants2-here with [size > 3]]) > 5)
 [ ask one-of patches with [any? plants1-here with [size > 3.5]]        ; Can you find out what is significant about these size numbers?
   [sprout-bees 1
     [set shape "bee 2"
       set color 4
       set energy 5
       set size 1]
   ]]]

    ]
end


;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;
;;                                                                                                           ;;
;;               The following lines indicate how the particular agents in the model GROW.                   ;;
;;                                                                                                           ;;
;;   Note that some agents don't grow at all.                                                                ;;
;;   You can try changing the RATE that agents grow by increasing or decreasing the number following         ;;
;;     the "set size +/-" command                                                                            ;;
;;   You can also try changing the CONDITIONS that determine when an agent grows by changing the numbers     ;;
;;     before or after the inequalities (< or >)                                                             ;;
;;   How do the two types of plant grow differently from each other?                                         ;;
;;                                                                                                           ;;
;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;

to plants1-grow
  if (energy > 3) [set size size + 0.02]
  if (size > 0.8) [set shape "plant medium"]
  if (size > 1.6) [set shape "plant"]
  if (size > 3.5) [set shape "flower 1"]
end

to plants2-grow
  if (energy > 3) [set size size + 0.01]
  if (size > 0.7) [set shape "plant medium 2"]
  if (size > 1.4) [set shape "tomato plant"]
  if (size > 3) [set shape "flower2"]
end

to weeds-grow;;
    if (energy > 2) [set size size + 0.04]     ; How do these numbers compare to the conditions for plant growth?
end

to farmers-grow
end

to drops-grow
end

to fungi-grow
if (hydration > 7) [set size size + 0.01]
if (hydration < 7) [set size size - 0.2]
end

to bees-grow            ; Bees don't actually grow in size in the model, so this shows how they look for food.
rt random 50             ; rt = "right turn", and a random number between 1 and 50
lt random 50             ; lt = "left turn". This positions the bees in a random direction before they move.
fd spacing-1             ; You could change this to any number.
set energy energy - 2.5  ; How much energy they lose each time they fly
end


;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;
;;                                                                                                           ;;
;;               The following lines indicate how the particular agents in the model EAT.                    ;;
;;  Note that some agents don't have code to eat because it isn't necessary to their function in the model.  ;;
;;  How do the agents interact differently with nutrients and hydration of the soil?                         ;;
;;  What impacts the gain or loss of energy?                                                                 ;;
;;                                                                                                           ;;
;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;

to plants1-eat
  if (nutrients >= 1 and (hydration >= 1  and hydration < 10)) ; Conditions that let the plant eat
  [
      set energy energy + 1
      set nutrients (nutrients - 0.2)
      set hydration (hydration - 0.2)
      ask neighbors4 [set nutrients (nutrients - 0.05)        ; "neighbors4" are the four patches with sides directly next to the patch
        set hydration (hydration - 0.05)                      ; How does the impact on the neighbor patches differ from the main patch?
        ask neighbors [set nutrients (nutrients - .02)        ; "neighbors" are the 8 patches adjacent/ in a circle around the patch
        set pcolor scale-color brown nutrients 10 0]          ; The color of the patches updates based on their new nutrient level
      set pcolor scale-color brown nutrients 10 0]]

  if (nutrients < 1  or hydration < 1)                        ; Conditions where the plant is unable to eat
  [
      set energy energy - 0.1]                                ; If no nutrients in the soil, this rate is how fast they will die

  if (hydration > 12) [                                       ; Conditions that lead to fungus also impact soil quality
    set nutrients (nutrients - 2)
 ask neighbors4
 [set nutrients (nutrients - .8)]
 ask neighbors4 [
    sprout-fungi 1
  [
  set shape "mushroom"
   set color white
   set size 0.3]]]
end


;;  This breed of plant (2) is more drought resilient, so it needs less water to be able to survive.      ;;
;;        But, it also grows slower.                                                                      ;;
;;  Try to change some of its properties (numbers written in brown) to make it behave differently.        ;;
;;  What other plants could you try to program based on how they interact with water and the soil?        ;;

to plants2-eat
  if (nutrients >= 1 and (hydration >= -5  and hydration < 15))
  [
      set energy energy + 1
      set nutrients (nutrients - 0.2)
      set hydration (hydration - 0.2)
      ask neighbors4 [set nutrients (nutrients - 0.05)
        set hydration (hydration - 0.05)
        ask neighbors [set nutrients (nutrients - .02)
        set pcolor scale-color brown nutrients 10 0]
      set pcolor scale-color brown nutrients 10 0]]
  if (nutrients < 1  or hydration < 1)
  [
      set energy energy - 0.1]

  if (hydration > 20) [
    set nutrients (nutrients - 2)
 ask neighbors4
 [set nutrients (nutrients - .8)]
 ask neighbors4 [
    sprout-fungi 1
  [
  set shape "mushroom"
   set color white
   set size 0.3]]]
end

to weeds-eat
  if (nutrients >= 1) [                               ; Do weeds have more or less restrictive conditions than other plants?
  set energy energy + 1
  set nutrients (nutrients - 0.1)                     ; How do weeds affect the soil quality, compared to other plants?
   set hydration (hydration - 0.1)
  ask neighbors4 [
     set hydration (hydration - 0.05)
    set nutrients (nutrients - 0.08)
    set pcolor scale-color brown nutrients 10 0]
  set pcolor scale-color brown nutrients 10 0]

  if (nutrients < 1) [                                ; Conditions where the weed is unable to eat
  set energy energy - 0.1]
end

to farmers-eat
end

to drops-eat
end

to fungi-eat
  set nutrients (nutrients - 0.1)
  set pcolor scale-color brown nutrients 10 0
end

to bees-eat                                        ; How could you change this procedure to better represent pollination?
if any? plants1-on neighbors [
 set energy energy + 5                             ; Bees get energy from being near plants
 ask plants1-on neighbors [set energy energy + 3]  ; Bees also give energy to the plants they visit
   ]
if any? plants2-on neighbors [
 set energy energy + 7
 ask plants2-on neighbors [set energy energy + 5]  ; Plant-2 gives the bees more energy
   ]
end

;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;
;;                                                                                                           ;;
;;               The following lines indicate how the particular agents in the model DIE.                    ;;
;;             Note that some agents don't have code to die because they are always in the model.            ;;
;;                                                                                                           ;;                                                                                         ;;
;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;

to plants1-check-if-dead
  if (energy <= 0) [
    set nutrients (nutrients + 0.5)               ; Plants add nutrients to the soil when they die
    set pcolor scale-color brown nutrients 10 0
    die
    ]
end

to plants2-check-if-dead
  if (energy <= 0) [
    set nutrients (nutrients + 0.4)
    set pcolor scale-color brown nutrients 10 0
    die
    ]
end

to weeds-check-if-dead
  if (energy <= 0) [ die ]                       ; Weeds don't produce compost when they die
end

to farmers-check-if-dead
end

to drops-check-if-dead                           ; Even though water isn't technically living, this removes them from the model
  set size size - 0.2
  die
end

to fungi-check-if-dead
if (hydration < 5) [die]
end

to bees-check-if-dead
  if (energy <= 0) [die]
end

;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;
;;                                                                                                           ;;
;;            The code below describes how you can harvest plants and weeds from the model                   ;;
;;                                                                                                           ;;
;;   Some things can be harvested, but don't count towards your 'total harvested' button.                    ;;
;;   Do you think this is fair? Which things should or should not be able to be sold for money?              ;;
;;   What else would you want to harvest? What else would you want to do with crops or weeds you pull up?    ;;
;;                                                                                                           ;;
;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;

to harvest-plants
  ask farmers [
    set hidden? not mouse-inside?
    setxy mouse-xcor mouse-ycor                 ; Farmer follows your mouse
  ]
  if mouse-inside? and mouse-down? [            ; Mouse-down means you are clicking/ holding click button
    set crop plants1 with                       ; Determining what counts as 'crop'
    [distance one-of farmers < (size / 2) and   ; Closeness to farmer
      size < 3.5]                               ; Size restrictions
    if any? crop [
      let weight sum [size] of crop             ; 'Weight' is a new global being defined here in this sequence ('let' does this)
      set total-harvested (                     ; It uses the size of the plant to determine how to increase your total harvest amount
        total-harvested +
        (ceiling (1.5 * weight * count crop)))  ; 'Ceiling' rounds up to the nearest whole number
ask crop [ die ]
    ]
    let flowers plants1 with [distance one-of farmers < (size / 2) and size > 3.5]
    if any? flowers [
      ask flowers [die]]
  ]



   ask farmers [                                ; Harvesting the second breed of plant
    set hidden? not mouse-inside?
    setxy mouse-xcor mouse-ycor
  ]
  if mouse-inside? and mouse-down? [
    let crop2 plants2 with
    [distance one-of farmers < (size / 2) and
      size < 3.5]
    if any? crop2 [
      let weight sum [size * 1.5] of crop2      ; This crop has a higher value when it is harvested
      set total-harvested (total-harvested +
        (ceiling (1.5 * weight * count crop2)))
ask crop2 [ die ]
    ]
    let flowers2 plants2 with [distance one-of farmers < (size / 2) and size > 3]
    if any? flowers2 [
      ask flowers2 [die]]
  ]
end

to harvest-weeds
  ask farmers [
    set hidden? not mouse-inside?
    setxy mouse-xcor mouse-ycor
  ]
  if mouse-inside? and mouse-down? [
    let weedable weeds with [distance one-of farmers < (size * 2)]
    if any? weedable [

ask weedable [ die ]
    ]
  ]
end

;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;
;;                                                                                                           ;;
;;             The code below describes the procedures for adding inputs to your garden                      ;;
;;                                                                                                           ;;
;;   Currently it contains compost, water, and herbicide (fungicide is defined inside the button             ;;
;;       on the interface.)                                                                                  ;;
;;   Do you think the way they function is realistic? What else should adding these things do?               ;;
;;   Is there anything else you would want to add to the garden? What about where these things get added?    ;;
;;   Currently these inputs all cost money. Do the prices seem realistic? Should they ever change?           ;;
;;                                                                                                           ;;
;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;

to add-compost
  ask patches [                                     ; All patches get compost
    set nutrients (nutrients + 5)
    set pcolor scale-color brown nutrients 10 0 ]   ; The color updates after based on new nutrient level
set money (money - 20)
end

to add-water
if not drought [                                    ; This procedure won't run during drought mode
ask patches [ set hydration (hydration + 5)
  sprout-drops 1
  [ set breed drops
    set shape "drop"
    set color sky
    set size 0.6]
    set pcolor scale-color blue hydration 10 0]     ; The color updates to show you the new hydration level
set money (money - 20)]
end

to add-herbicide
  ask weeds [die]
  ask plants1 [
    set energy energy - 2]
  ask patches [set nutrients (nutrients - 2)
    set pcolor scale-color brown nutrients 10 0 ]
set money (money - 30)
set pesticide-ppm (pesticide-ppm + 1)               ; This keeps track of how many times you apply chemicals
end
