Neighborhoods Example

;;  This procedure creates 8 turtles in puts them in a circle,
;;  and moves three to the edges of the world

to setup
  ca
  crt 8
  [ fd 10 ]
  ask turtle 0 [ fd 7 ]
  ask turtle 1 [ fd 14 ]
  ask turtle 2 [ fd 7 ]
end

;;  This procedure colors all the patches neighboring each turtle.
;;  neighbors reports the eight patches surrounding the turtle.
;;  Note that patches have neighbors as well, and can also use the neighbors reporter.

to paint-neighbors
  clear-patches
  ask turtles
    [ paint-agents neighbors ]
end

;;  This procedure is similar to paint-neighbors, but uses the neighbors4 reporter.
;;  neighbors4 reports only the four patches adjacent to the current patch, and does not include
;;  the four neighbors which are only diagonally touching the current patch.
;;  As with neighbors, both turtles and patches can use neighbors4.

to paint-neighbors4
  clear-patches
  ask turtles
    [ paint-agents neighbors4 ]
end

;;  This procedure uses in-radius to paint a "circle" around each turtle.
;;  "agentset in-radius n" reports those agents in agentset whose distance from the current agent
;;  is less than or equal to n. For patches, distance is measured from the center of the patch.
;;  Note that the caller can be a turtle or a patch, and agentset can be a set of turtles or a set of
;;  patches, so you can also use in-radius to locate turtles within a given radius
;;  of another turtle or patch.  Also notice that the reported agentset includes the patch that the
;;  turtle is currently on.

to paint-in-radius
  clear-patches
  ask turtles
    [ paint-agents patches in-radius radius ]
end

;;  This procedure uses the at-points reporter to paint an arbitrary neighborhood.
;;  at-points lets you specify groups of agents on individual patches, using points
;;  relative to the calling agent (so [0 0] indicates the patch the agent is on).
;;  As with the above primitives, at-points can be used by both turtles and patches.

to paint-at-points
  clear-patches
  ask turtles
  [
    if points = "corners"
      [ paint-agents patches at-points [[1 1] [-1 1] [-1 -1] [1 -1 ]] ]
    if points = "left"
      [ paint-agents patches at-points [[-1 1] [-1 0] [-1 -1]] ]
    if points = "L-shape"
      [ paint-agents patches at-points [[-1 1] [-1 0] [-1 -1] [0 -1] [1 -1 ]] ]
    if points = "line-up"
      [ paint-agents patches at-points [[0 1] [0 2] [0 3] [0 4]] ]
  ]
end

;; This is a helper procedure, used to set the color of a set of patches.

to paint-agents [agents]
  ask agents [ set pcolor [color] of myself - 2 ]
end


; Public Domain:
; To the extent possible under law, Uri Wilensky has waived all
; copyright and related or neighboring rights to this model.
