Next Patch Example

;; This stuff is just for demoing purposes.  The NEXT-PATCH procedure,
;; below, is the real meat of the code example.

turtles-own [next prev]

to setup
  clear-all
  crt 1
    [ set color green
      set next patch-here
      set prev patch-here
      set pcolor gray ]
  reset-ticks
end

to go
  ask turtles
    [ ask next [ set pcolor black ]
      ask prev [ set pcolor black ]
      set prev patch-here
      ;; Note that even going fd 0.01 might still cross two patch boundaries.
      ;; No matter how small a finite distance you move forward, you might
      ;; jump right over the corner of a patch.  But this is fine for demo
      ;; purposes.
      fd 0.01
      ask prev [ set pcolor gray ]
      set next next-patch
      ask next [ set pcolor red ] ]
  tick
end

;; Here's the important procedure.  The idea behind it is to
;; compare the turtle's current heading to the headings to the
;; corners of the patch it is standing on.

to-report next-patch  ;; turtle procedure
  if heading < towardsxy (pxcor + 0.5) (pycor + 0.5)
    [ report patch-at 0 1 ]
  if heading < towardsxy (pxcor + 0.5) (pycor - 0.5)
    [ report patch-at 1 0 ]
  if heading < towardsxy (pxcor - 0.5) (pycor - 0.5)
    [ report patch-at 0 -1 ]
  if heading < towardsxy (pxcor - 0.5) (pycor + 0.5)
    [ report patch-at -1 0 ]
  report patch-at 0 1
end

;; The above code is good enough for most practical purposes, but it glosses
;; over a few subtleties that you might conceivably care about.
;;
;; The above code always returns one of the four neighboring patches
;; (north, south, east, west), aka NEIGHBORS4 or the "Von Neumann
;; neighborhood".  It never returns a diagonal neighbor.
;;
;; If the turtle is headed directly for the corner of its patch, though,
;; it would be more correct to return a diagonal neighbor in that
;; case.  If the turtle's heading was determined by RANDOM-FLOAT, then
;; such a situation is vanishingly unlikely.  Anyway, the inherent imprecision
;; of floating point math and the lack of continuous motion in NetLogo means
;; that depending on what you're doing, it is probably not useful or meaningful
;; to talk about whether the turtle is headed exactly at a corner.
;;
;; There's an even further subtlety in that NetLogo patches are closed on
;; their south and west boundaries and open on their north and east
;; boundaries.  That means that the point where four patches meet always
;; belongs to the northeastern patch.  So if you want the diagonal patches,
;; you have to decide how to handle the case where the turtle is pointed
;; exactly at a corner.  Do you want to always return the northeastern
;; patch at that corner, even though the turtle's path may only intersect
;; that patch at a single point?  Or do you want to ignore the corner point
;; and look at the patch that lies just beyond that point?  The following
;; code implements the latter choice.
;;
;; This version does more work than the four-neighbor version,
;; so it will run more slowly.  In most situations, we suggest
;; just sticking with the four-neighbor version.

to-report next-patch-8  ;; turtle procedure
  let diff heading - towardsxy (pxcor + 0.5) (pycor + 0.5)
  if diff < 0 [ report patch-at 0 1 ]
  if diff = 0 [ report patch-at 1 1 ]
  set diff heading - towardsxy (pxcor + 0.5) (pycor - 0.5)
  if diff < 0 [ report patch-at 1 0 ]
  if diff = 0 [ report patch-at 1 -1 ]
  set diff heading - towardsxy (pxcor - 0.5) (pycor - 0.5)
  if diff < 0 [ report patch-at 0 -1 ]
  if diff = 0 [ report patch-at -1 -1 ]
  set diff heading - towardsxy (pxcor - 0.5) (pycor + 0.5)
  if diff < 0 [ report patch-at -1 0 ]
  if diff = 0 [ report patch-at -1 1 ]
  report patch-at 0 1
end


; Public Domain:
; To the extent possible under law, Uri Wilensky has waived all
; copyright and related or neighboring rights to this model.
