PANDA BEAR Solo

;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;
;; Variable and Breed declarations ;;
;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;

globals [
  red-vertex          ;; the red vertex
]

breed [ vertices vertex ]

;; vertices keep track of who is next in line
;; because the area calculation requires it.
vertices-own [ next-vertex ]

;;
;; Setup Procedures
;;

;; Initializes the display, and creates a list that contains the names of the shapes
;; used by turtles in this activity.  Also initializes the data lists.

to setup
  clear-all
  set-default-shape vertices "circle"
  create-vertices number-vertices [
    setup-vertex-vars
  ]
  ;; one of the vertices is specially controlled by the
  ;; controls in the interface, designate it here.
  ask one-of vertices [
    set color red
    set shape "monster"
    set red-vertex self
  ]
  ;; make the polygon
  ask one-of vertices [ edgify ]
  ;; update the data in the display
  update
end

;; sets the turtle variables to appropriate initial values

to setup-vertex-vars  ;; vertex procedure
  set color brown
  setxy random-xcor random-ycor
  set heading 0
  set label-color white
  set next-vertex nobody
end

;; recursive procedure that links all the vertices together
;; one at a time.

to edgify
  ;; each vertex is linked to once and then, in turn links to
  ;; another vertex that has not yet been linked, when we
  ;; run out of vertices we've made a line and we just need
  ;; to close the polygon by linking back to the beginning
  let candidates other vertices with [ not any? link-neighbors ]
  ifelse any? candidates
  [
    set next-vertex one-of candidates
    create-link
    ask next-vertex [ edgify ]
  ]
  [
    set next-vertex one-of other vertices with [ count link-neighbors = 1 ]
    create-link
  ]
end

to create-link
  create-link-with next-vertex [
    set color white
    set label-color white
  ]
end

;;
;; Runtime Procedures
;;

to go
  if mouse-down? [
    ;; clicking "picks up" the closest vertex
    ask min-one-of vertices [ distancexy mouse-xcor mouse-ycor ] [
      ;; if the mouse is more than 1 patch away from any
      ;; vertex just ignore the click.
      if distancexy mouse-xcor mouse-ycor < 1
      [
        while [mouse-down?] [
          ;; use EVERY to limit how much data we end up plotting
          every 0.05 [
            ;; don't move vertices directly on top of one another
            if all? other vertices [ xcor != mouse-xcor or ycor != mouse-ycor ] [
              setxy mouse-xcor mouse-ycor
              update
            ]
          ]
        ]
      ]
    ]
  ]
end

to update
  ask links [
    set label less-precise link-length
  ]
  ask vertices [
    ;; make sure the angle is positive
    let my-neighbors sort link-neighbors
    let angle (subtract-headings towards first my-neighbors towards last my-neighbors) mod 360
    ;; make sure the angle is the interior angle
    if angle > 180 [ set angle 360 - angle ]
    set label less-precise angle
  ]
  display
  update-plots
end

;;; used to keep the labels from having too much cluttering detail

to-report less-precise [ precise-num ]
  report precision precise-num 1
end

to-report perimeter
  report sum [link-length] of links
end

;; this area calculation is based on the formula found here:
;; http://mathworld.wolfram.com/PolygonArea.html

to-report area
  let result 0
  ask vertices [
    let addend ((xcor * [ycor] of next-vertex) -
        (ycor * [xcor] of next-vertex))
    set result result + addend
  ]
  report abs (result / 2)
end


;; red-vertex commands

to move-fd
  ask red-vertex [
    ;; pre-check that no other vertices are on the point we're headed to
    let new-xcor (xcor + step-size * dx)
    let new-ycor (ycor + step-size * dy)
    if all? vertices [xcor != new-xcor or ycor != new-ycor] [
      fd step-size
    ]
  ]
  update
end

to move-bk
  ask red-vertex [
    ;; pre-check that no other vertices are on the point we're headed to
    let new-xcor (xcor + step-size * (- dx))
    let new-ycor (ycor + step-size * (- dy))
    if all? vertices [xcor != new-xcor or ycor != new-ycor] [
      bk step-size
    ]
  ]
  update
end

to turn-right
  ask red-vertex [
    rt turn-amount
  ]
end

to turn-left
  ask red-vertex [
    lt turn-amount
  ]
end


; Copyright 2007 Uri Wilensky.
; See Info tab for full copyright and license.
