Olympia Virus Spread

No preview image

1 collaborator

Default-person Anna Singley (Author)

Tags

(This model has yet to be categorized with any tags)
Visible to everyone | Changeable by the author
Model was written in NetLogo 6.1.0 • Viewed 33 times • Downloaded 0 times • Run 0 times
Download the 'Olympia Virus Spread' modelDownload this modelEmbed this model

Do you have questions or comments about this model? Ask them here! (You'll first need to log in.)


Comments and Questions

Please start the discussion about this model! (You'll first need to log in.)

Click to Run Model

globals [ ; general globals
  healthy
  infected
  dead
  total-infected
]
breed [people person]
breed [cities city] ; megacities with over 10 million people
breed [infecthalo infects] ; highlights patient zero
people-own [
  mode ; 0 (human) or "plane" (plane)
  destination ; for when mode = "plane", decides what city to land at
  ; infection variables
  infected? ; true (yes) or 0 (no)
  time-till-symptoms ; decided by avg.-incubation-period and incubation-period-range
  symptom-length ; days till recover or die, decided by symptom-length-(lowest/highest)
  reproductive-ratio ; how many people someone with the disease can spread it to? decided by avg.-reproductive-ratio and reproductive-ratio-range
  die-from-disease? ; how long till die? true or false (will recover)
  got-disease? ; if someone gets and recovers from disease, true or 0 (false)
]
cities-own [
  name
  population
]

extensions [import-a fetch]

to Setup
  ca ; clears everything
  reset-ticks ; resets clock
  decide-disease-variables
  make-cities
  import-pcolors "oly.png"; image seen in background gets loaded in (must be in same folder)
  ask patches with [pcolor >= 8.1 and pcolor <= 8.3] [set pcolor 7.8] ; make more patches land
  ask patches with [pcolor >= 7.2 and pcolor <= 7.5] [set pcolor 7.8] ; make more patches land
  ask patches with [pcolor = 7.8] [if count neighbors with [pcolor = 7.8] = 0 [set pcolor 7]] ; so turtles don't get stuck on single patches of land
  ask patches with [pxcor > max-pxcor - 4 or pxcor < min-pxcor + 4 or pcolor = 39.9] [set pcolor 9.9] ; so more of white is water
  set-default-shape people "person"
  set-default-shape infecthalo "thin ring"
  let pre-move 100
  while [pre-move > 0] [ ; people move out from cities for (pre-move) number of cycles
    ask people [move]
    set pre-move pre-move - 1
  ]
  set healthy count people
  first-infected ; patient zero setup
end

to decide-disease-variables ; depending on disease, inputs variables automatically
  if disease-variables = "COVID-19" [
    set patient0-x 0
    set patient0-y 0
    set fatality-rate 2
    set avg.-reproductive-ratio 6
    set reproductive-ratio-range 1
    set avg.-incubation-period 5      ;
    set incubation-period-range 5
    set symptom-length-lowest 14
    set symptom-length-highest 21
    set get-again? true
  ]
  if disease-variables = "Measles" [
    set patient0-x -254
    set patient0-y 5
    set fatality-rate 10
    set avg.-reproductive-ratio 15
    set reproductive-ratio-range 3
    set avg.-incubation-period 14
    set incubation-period-range 14
    set symptom-length-lowest 7
    set symptom-length-highest 14
    set get-again? false
  ]
  if disease-variables = "Ebola" [
    set patient0-x -9
    set patient0-y -55
    set fatality-rate 50
    set avg.-reproductive-ratio 2
    set reproductive-ratio-range .5
    set avg.-incubation-period 10
    set incubation-period-range 8
    set symptom-length-lowest 8
    set symptom-length-highest 10
    set get-again? false
  ]
end

to make-cities
  create-cities 43 [
    set size 3
    set shape "circle"
    set color black
    set label-color black
    if who = 0 [ set name "School" set population .0002 setxy 0 0] ; populations rounded to nearest half million
    if who = 1 [ set name "Armington" set population .0001 setxy 45 -13]
    if who = 2 [ set name "Seoul" set population .0001 setxy 67 77]
    if who = 3 [ set name "Shanghai" set population .0001 setxy 86 -37]
    if who = 4 [ set name "Mumbai" set population .0001 setxy 57 -33]
    if who = 5 [ set name "Mexico City" set population .0001 setxy -61 -28]
    if who = 6 [ set name "Beijing" set population .0001 setxy 28 -84]
    if who = 7 [ set name "Sao Paulo" set population .0001 setxy -42 -33]
    if who = 8 [ set name "Jakarta" set population .0001 setxy 94 -85]

  ]
  let citypop sum [population] of cities
  let worldpop 7300 / #-people-per-agent ; 7.30 billion people, if each agent = 5mil people, then 1460 agents
  ask cities [
    hatch-people (round ((population / citypop * worldpop) + .02)) [ ; each city creates proportional amount of people based on population
      set infected? false
      set color green
      set size 10
      set heading random 360
    ]
  ]
end

to first-infected
  ifelse patient0-x = 0 and patient0-y = 0 ; if no patch chosen,
  [
    ask one-of people [ ; ask random person to be infected
      become-infected
      make-infecthalo
    ]
  ]
  [
    ask patch patient0-x patient0-y [ ; else, ask person closest to patch chosen
      ask min-one-of people [distance myself] [
        become-infected
        make-infecthalo
      ]
    ]
  ]
end

to make-infecthalo
  hatch-infecthalo 1 [
    set size 20
    ;; Use an RGB color to make halo three fourths transparent
    set color lput 64 extract-rgb color
    ;; set thickness of halo to half a patch
    ;; We create an invisible directed link from the runner
    ;; to the halo.  Using tie means that whenever the
    ;; runner moves, the halo moves with it.
    create-link-from myself [
      tie
      hide-link
    ]
  ]
end

;;=========================================;;

to become-infected
  set infected? true
  set infected infected + 1 ; updates appropriate globals
  if got-disease? != true [set total-infected total-infected + 1]
  set healthy healthy - 1
  set color red
  set time-till-symptoms round (avg.-incubation-period + random-float (.5 * incubation-period-range) - random-float (.5 * incubation-period-range)) ; days until can spread disease
  set symptom-length symptom-length-highest - round (random-float symptom-length-lowest) ; how long symptoms last until heal or die
  set reproductive-ratio round (avg.-reproductive-ratio + random-float (.5 * reproductive-ratio-range) - random-float (.5 * reproductive-ratio-range)) ; number of people that infected can infect
  ifelse random 100 < fatality-rate ; determines if will die from disease
  [
    set die-from-disease? true
  ]
  [
    set die-from-disease? false
  ]
end

to become-healthy
  set infected? false
  set healthy healthy + 1 ; updates appropriate globals
  set infected infected - 1
  set color green
  set got-disease? true
end

to become-dead
  set dead dead + 1 ; updates appropriate globals
  set infected infected - 1
  die ; a dead agent ceases to exist
end

;;=========================================;;

to StartVirus
  city-selector ; visual to show city name
  ask people with [mode = 0] [
    move
    if infected? [ ; red person
      if time-till-symptoms = 0 [
        infect
        if symptom-length = 0 [
          ifelse die-from-disease?
          [
            become-dead
          ]
          [
            become-healthy
          ]
        ]
        if symptom-length > 0 [
          set symptom-length symptom-length - 1
        ]
      ]
      if time-till-symptoms > 0 [
        set time-till-symptoms time-till-symptoms - 1
      ]
    ]
  ]
  ask people with [mode = "plane"] [
    fd 10
    if distance destination <= 5 [ ; turn into person if close to city
      set mode 0
      set size 4
      move-to destination
      set destination 0
      set shape "person"
      set heading random 360
    ]
  ]
  ask cities [
    attract
    airport-run
  ]
  ask infecthalo [
    if infected != 1 [
      die
    ]
  ]
  tick
  wait .005
end

to city-selector
  ask patch mouse-xcor mouse-ycor [ ; if mouse is over city, display name
    let x (cities in-radius 3)
    if any? x [
      ask x [
        set label name
        if mouse-down? [; if mouse clicks on city, displays city info
          clear-output
          output-print name
          output-type "Population = " output-type population output-print " million"
        ]
      ]
    ]
    ask cities with [label != "" and distance myself > 3] [ ; if mouse goes off city that is displaying info, resets
      set label ""
      clear-output
    ]
  ]
end

to move
  if random 2 = 0 [ ; 50% chance to change direction
    set heading heading + random 20 - random 20 ; change direction
  ]
  while [patch-ahead 1 = nobody or [pcolor] of patch-ahead 1 = 9.9] [ ; change direction if water is ahead
    set heading heading + random 20 - random 20
  ]
  fd 1 ; moves forword a patch per day
  if distance min-one-of cities [distance myself] > 50 [ ; if too far from cities, face closest city
    face min-one-of cities [distance myself]
  ]
end

to infect
  let x people in-radius 2 with [infected? = false and mode = 0] ; who can be infected
  if get-again? = false [ ; if disease cannot infect a person more than once, new restraint
    set x people in-radius 2 with [infected? = false and mode = 0 and got-disease? = 0]
  ]
  if any? x and reproductive-ratio > 0 [ ; if any people to infect and can infect more people
    ifelse count x <= reproductive-ratio ; if less people to infect than can infect
    [ ; infect those people and reduce reproductive-ratio
      set reproductive-ratio reproductive-ratio - count x
      ask x [
        become-infected
      ]
    ]
    [ ; else infect all people possible and set reproductive ratio 0
      ask n-of reproductive-ratio x [
        become-infected
      ]
      set reproductive-ratio 0
    ]
  ]
end

to attract
  if count people with [mode = 0] in-radius 5 < population / 10  and count people with [mode = 0] > population / 10[ ; if less people in-radius than population,
    ask min-n-of (population / 10 - count people with [mode = 0] in-radius 5) people with [mode = 0] [distance myself] [ ; ask closest people to face city
      face myself
    ]
  ]
end

to airport-run
  if random 175 = 0 and count people with [mode = 0] in-radius 5 > population / 40 [ ; random chance to create airplane
    ask one-of people with [mode = 0] in-radius 5 [
      set mode "plane"
      set shape "airplane"
      set size 5
      set destination one-of cities
      face destination
    ]
  ]
end

There are 3 versions of this model.

Uploaded by When Description Download
Anna Singley about 1 month ago fixed bug Download this version
Anna Singley about 1 month ago fixed bug Download this version
Anna Singley about 1 month ago Initial upload Download this version

Attached files

File Type Description Last updated
oly.PNG png bg image about 1 month ago, by Anna Singley Download

This model does not have any ancestors.

This model does not have any descendants.
