MES_Repository preview image

1 collaborator

Patarakin_m Evgeny Patarakin (Author)

Tags

(This model has yet to be categorized with any tags)
Visible to everyone | Changeable by everyone
Model was written in NetLogo 6.1.1 • Viewed 24 times • Downloaded 1 time • Run 0 times
Download the 'MES_Repository' modelDownload this modelEmbed this model

Do you have questions or comments about this model? Ask them here! (You'll first need to log in.)


Comments and Questions

Please start the discussion about this model! (You'll first need to log in.)

Click to Run Model

;; Models with user - which has administrative function they don't patrucipate in creation, but they organize space - School-Leader

extensions [nw csv table rnd] ;; расширение - показать как именно они используются

directed-link-breed  [bonds bond] ; Links between gamers

;; patches-own [pagenum]

breed [users user]  ;; порода участников - авторы и редакторы сценариев
breed [balls ball]  ;; breed of object - scenarious that are created by users

turtles-own [
  nearest-neighbor   ;; closest one of our flockmates
]

users-own [
agentname   ;; ID of user
  School   ;; School of user - Eeach user linked with only one school
  Age      ;; Age of use - how we can use it ?
  Gender   ;; How we can use gender in this model   - выбираются по тому, насколько они близки
  User_Subj  ;; List of disciplins this user has teach

  ;;
  action
  t-pagenum

  region_point ;; place of birth
]


balls-own [
 Ball_Subj  ;; Subject of page - maded by first user who create this page
  pagenum ;; ID of Page
  impuls ;; impuls - after creation or reuse
  Gender  ;; for affinity
]

links-own [weight]

globals [
 ;; wikihistory ;
  wikilog ;  log file - creating & reusing of scenarious
  pages ;; перечень созданных страниц - мы используем число элементов в списке при присваивании имени новому сценарию


  ]


;;; Очистили,  закрыли и обнулили все,

to setup
clear-all ;
file-close;
   set-default-shape users "person" ;
  set-default-shape balls "circle" ;
 ;;   set-default-shape users "circle" ;
   set-default-shape bonds "default" ;
 ;; set wikihistory [] ;
  set wikilog [] ;
  set pages [] ; исходно пустой список


  let R 8
  let teachers_in_school round (Pl_number / ((R - 1) ^ 2))


  let SBJ ["Math" "Literature" "Russian" "Biology" "Chemistry" "Informatics" "Geography" "Astronomy"]


  let N_SBJ [1 2 3 4 5 6 7 8]  ;; сколько  будет

   let weights [ 0.9 0.7 0.6 0.5 0.4 0.3 0.1 0.05]
      let s_pairs (map list SBJ weights)
     let n_pairs (map list N_SBJ weights)
 ;;   type first rnd:weighted-one-of-list n_pairs [ [p] -> last p ]




    ask patches with [pxcor mod R = 0 and pycor mod R = 0]
  [
    sprout-users
    1 + random   ;; - if we think that there is different quantity of teachers
    teachers_in_school [
    set color white
    set size 1
    set agentname who
    set region_point patch-here

    set action 0  ;; action 0 - ничего


      ;;
      set User_Subj map first rnd:weighted-n-of-list
      first rnd:weighted-one-of-list n_pairs [ [p] -> last p ]
      s_pairs [ [s] -> last s ]


   ;;n-of (1 + (random length SBJ) ) SBJ   ;; What it means



    set Gender one-of  ["Female" "Male"]  ;; Пол агента - пока никак не используется, если мы не создадим сегрегацию или присоединение
    set Age one-of  n-values 50 [18 + random 50]
    set School remove "patch" word "School_N_"  region_point ;;;

    find_empty_space
    ;;
]
  ]
  let B 16
    let balls_in_school round (B_number / 9)
          ask patches with [pxcor mod B = 0 and pycor mod B = 0]
  [

  sprout-balls balls_in_school [
      set color blue
    set impuls 0
    set size 0.6
    set Ball_Subj 0 ;;


    set pagenum 0
      find_empty_space
   ;;    setxy random-xcor random-ycor
  ;; ht
  ]
  ]
update-School-plot
update-n_u_plot
reset-ticks
end

to  find_empty_space
  ifelse not any? other users-here [stop]
  [rt 360 fd 0.5  find_empty_space]
end

to go
;;    if length reused > length created [stop]
;;  ask users with [ (any? balls-here )] [touch_ball one-of balls-here ]
  ask users with [not any? balls-here ] [ search_ball ]
  ask balls [
  ball_move
  ]
  ask users [find_empty_space]
 ;; update-Subjects-plot
  tick
end

to ball_move
  if any? users-here [
    ;; it is ball choice   ;;  А кого именно выбирает сценарий, если есть выбор из нескольких ???
    ;; affinity to Gender



    ifelse pagenum = 0
    [
    let player one-of users-here ;; выбираем любого
      let newpage 1 + length pages
       set pages lput newpage pages
      set pagenum  newpage ;;
      set Ball_Subj one-of [User_Subj] of player ;;
      set Gender [Gender] of player ;;
      set wikilog lput (se [who] of player pagenum "create" [School] of player Ball_Subj ) wikilog
      set heading [heading] of player
      set color green
      st ;; show created scenario
         fd ball_shift ;; как далеко уходит сценарий от автора? - свойство самого сценария - регулируется в системе. Если
    ]

    [
   let player one-of users-here

     ifelse not Subj_Segregation
          [ set wikilog lput (se [who] of player pagenum "reuse" [School] of player Ball_Subj) wikilog ]
      [

      ifelse not member? Ball_Subj  [User_Subj] of player  [ ]   ;; если есть предпочтение по предмету, то с чужим автором связь не образуется
             [ set wikilog lput (se [who] of player pagenum "reuse" [School] of player Ball_Subj) wikilog ]

      ]



        set heading [heading] of player
      set color orange
         fd ball_shift
    ]
    ]
end

to search_ball
  if count balls
  ;; with [member? Ball_Subj [User_Subj] of myself  ]
  in-cone vision 360 > 0

  [ let myball one-of balls
    ;; with [member? Ball_Subj [User_Subj] of myself  ]
    in-cone vision 360
set heading towards myball
    if distance region_point <  stay_school [ fd 0.5 ]
    if distance myball < 0.5 [move-to myball]
  ]
end

;;

;;;;;;;
;; user scenario action school subject

to save_log
set wikilog fput (se  "user" "scenario" "action" "school_user" "subject" ) wikilog
 let exp1 (word "experiments/netlogo" experiments ".csv")
  csv:to-file exp1 wikilog
end


;; Just use csv:to-file "/path/to/myfile.csv" my-data!

;;  Данные по созданию и использованию объектов

to-report reused
report filter [ [?1] -> "reuse" = item 2 ?1 ] wikilog
end

to-report created
report filter [ [?1] -> "create" = item 2 ?1 ] wikilog
end



;;;;;;;;;;;;;;;;;;;;;

to logs_to_sociogram
;; ask balls [ht]
 ;; ask users [set color red]
  ;; пока связи идут только от редакторов к автору статьи
  foreach reused [ [?1] ->
    let friend1 item 0 ?1
    let p1 item 1 ?1
    let friend2 first first filter [ [??1] -> (p1 = item 1 ??1) and ("create" = item 2 ??1) ] wikilog
    if friend1 != friend2 [
    ask user friend1 [ create-bond-to turtle friend2 ]
    ]

    ]

 ;; repeat 8 [layout-spring  users links 1 5 7 ]
leaders_distribution
  follower_distribution
end






;;;;;;

to update-School-plot
  set-current-plot "Users Schools"
  clear-plot
  let counts table:counts [ School ] of users
  let schools sort table:keys counts
  let n length schools
  set-plot-x-range 0 n
  let step 0.05 ; tweak this to leave no gaps
  (foreach schools range n [ [s i] ->
    let y table:get counts s
    let c hsb (i * 360 / n) 50 75
    create-temporary-plot-pen s
    set-plot-pen-mode 1 ; bar mode
    set-plot-pen-color c
    foreach (range 0 y step) [ _y -> plotxy i _y ]
    set-plot-pen-color black
    plotxy i y
    set-plot-pen-color c ; to get the right color in the legend
  ])
end

;;;

to update-Subjects-plot
  set-current-plot "Scenarious Subjects"
  clear-plot
  let counts table:counts [ Ball_Subj ] of balls with [Ball_Subj != 0]
  let b-sbj sort table:keys counts
  let n length b-sbj
  set-plot-x-range 0 n
  let step 0.05 ; tweak this to leave no gaps
  (foreach b-sbj range n [ [s i] ->
    let y table:get counts s
    let c hsb (i * 360 / n) 50 75
    create-temporary-plot-pen s
    set-plot-pen-mode 1 ; bar mode
    set-plot-pen-color c
    foreach (range 0 y step) [ _y -> plotxy i _y ]
    set-plot-pen-color black
    plotxy i y
    set-plot-pen-color c ; to get the right color in the legend
  ])
end

;; распределение участников по числу дисциплин, сценарии для которых они создают

to update-n_u_plot
    set-current-plot "User_N_Subjects"
  clear-plot ;
  set-current-plot-pen "Pen1"
  histogram [length User_Subj] of users
 ;; set-histogram-num-bars number
end

;; распределение участников-агентов по числу связей, которые к ним идут от других участников

to leaders_distribution
 let max-in max [count my-in-links] of users
  set-current-plot   "Leaders"
    clear-plot ;
  set-current-plot-pen "L2"
  set-plot-x-range 0 max-in
set-plot-y-range 0 count users
set-histogram-num-bars max-in

  histogram [count my-in-links] of users
end

;;; распределение участников-агентов по числу связей, которые идут от  них к другим участникам

to follower_distribution
   let max-out max [count my-out-links] of users
    set-current-plot   "Followers"
    clear-plot ;
  set-current-plot-pen "F2"
    set-plot-x-range 0 max-out
  set-histogram-num-bars max-out
  histogram [count my-out-links] of users
end



;; histogram map first wikilog
