;__includes[ "social-model.nls" ]
; Note: all code is in the same page to allow for simulations in BehavioralSpace

;; CREATE WORLD
extensions [gis]

globals [ ;; recall that 'global' variables are accessed by ALL types (patches, turtles, etc.) // they all receive the same value // sliders, choosers, etc. are all globals
  ambit-dataset ;; this stores the project data
  MCSC_R-dataset
  ;; land areas percentages
  conifers evergreen schrubland waterfield no-land land-area
  ;; ECOLOGICAL INTERACTIONS
  bwater-conifer bwater-evergreen ET-conifer ET-evergreen
  ;; global? precipitation
  dry-forests dry-conifers dry-evergreen dry-schrubland forest-mass precipitation
  ; counters
  ha-multi-total ha-multi multi-ha multi-per count-multi ha-envir-total ha-envir envir-ha envir-per count-envir ha-maxim-total
  ha-tradi-total ha-tradi tradi-ha tradi-per count-tradi ha-passi-total ha-passi passi-ha count-passi passi-per ha-optim-total
  ; to speed the program
  conifer-multi evergreen-multi conifer-envir evergreen-envir
  conifer-tradi evergreen-tradi conifer-passi evergreen-passi
  territory
  ; because "if ticks n mod = 0 [" not working
  drought-list short-conifer long-conifer short-evergreen long-evergreen rc-bwater re-bwater
]

;; Give an identity to forest owners (Maximizers, etc.)
breed [maximizers maximizer]
breed [optimizers optimizer]
breed [traditionalists traditionalist]
breed [passives passive]
breed [multifunctionalists multifunctionalist]
breed [environmentalists environmentalist]

patches-own [
  popu         ;; species/polygons in vector data
  landcover    ;; types
  age drought bwater managed
  land-use     ;; used for extensions if having agriculture makes a difference
  belong-to management-plan id-owner
]

to setup
  ca
  set-current-directory "....." ; add your directory using \\ instead of /

  load-map
  paint-world ;; add color depending on land cover
  count-species ;; keep track of the land cover composition
  base-scenario
  add-land-use
  add-owners
  count-ha
  distribute-management-plans
  tickers

  file-close
  reset-ticks
end

to load-map
  ;; credit to: https://stackoverflow.com/questions/33437711/extension-exception-1944553-while-applying-raster-netlogo-gis
  set MCSC_R-dataset gis:load-dataset "mcsc_raster.asc" ;; loading the vector data
  resize-world 0 gis:width-of MCSC_R-dataset - 1 0 gis:height-of MCSC_R-dataset - 1
  gis:set-world-envelope-ds gis:envelope-of MCSC_R-dataset
  gis:apply-raster MCSC_R-dataset popu
end

to paint-world ; see Excel "Vector-excel" in folder "GIS"
   ask patches [
    if popu = 1 [ set pcolor 64      ; "pi roig"
      set landcover "conifers" ]
    if popu = 2 [ set pcolor 56      ; "matollar"
      set landcover "schrubland" ]
    if popu = 3 [ set pcolor 62      ; "pinassa"
      set landcover "conifers" ]
    if popu = 6  [ set pcolor 76     ; "pi blanc"
      set landcover "conifers" ]
    if popu = 5 [ set pcolor 52      ; "altres: roure/alzina"
      set landcover "evergreen" ]
    if popu = 4 [ set pcolor 88      ; "camp o aigua"
      set landcover "waterfield" ]
    if pcolor = black [              ; black = no map
      set landcover "no-land" ]
  ]
end

to base-scenario
   ask patches [
     set age random (150 - 20 + 1) + 20   ;; choose a random number between 20 and 150
     set drought 0
     set managed "No" ]
   ask patches [
      if landcover = "conifers" [
        set bwater (100 - initial-ET-conifer) ]
      if landcover = "evergreen" [
        set bwater (100 - initial-ET-evergreen) ]
   ]
  set precipitation initial-rain
  set ET-conifer initial-ET-conifer
  set ET-evergreen initial-ET-evergreen
end

to count-ha
  ; initialize global agentsets of patches by landcover (to speed up the model)
  set conifer-multi patches with [ belong-to = "multifunctionalists" and landcover = "conifers" ]
  set evergreen-multi patches with [ belong-to = "multifunctionalists" and landcover = "evergreen" ]
  set conifer-envir patches with [ belong-to = "environmentalists" and landcover = "conifers" ]
  set evergreen-envir patches with [ belong-to = "environmentalists" and landcover = "evergreen" ]
  set conifer-tradi patches with [ belong-to = "traditionalists" and landcover = "conifers" ]
  set evergreen-tradi patches with [ belong-to = "traditionalists" and landcover = "evergreen" ]
  set conifer-passi patches with [ belong-to = "passives" and landcover = "conifers" ]
  set evergreen-passi patches with [ belong-to = "passives" and landcover = "evergreen" ]

  set ha-maxim-total ( count patches with [ belong-to = "maximalists" ] )
  set ha-optim-total ( count patches with [ belong-to = "optimizers" ] )
  set ha-multi-total ( count patches with [ belong-to = "multifunctionalists" ] )
  set ha-envir-total ( count patches with [ belong-to = "environmentalists" ] )
  set ha-tradi-total ( count patches with [ belong-to = "traditionalists" ] )
  set ha-passi-total ( count patches with [ belong-to = "passives" ] )
end

to count-species
  ;; create a group based on each land to check all is fine (landcover = 100%, see observer in interface)
  set land-area (count patches with [ pcolor != black ])
  set conifers ((count patches with [ landcover = "conifers" ]/ land-area) * 100) ;; percentage of land area
  set evergreen ((count patches with [ landcover = "evergreen" ]/ land-area) * 100)
  set schrubland ((count patches with [ landcover = "schrubland" ]/ land-area) * 100)
  set waterfield ((count patches with [ landcover = "waterfield" ]/ land-area) * 100)
  set no-land ((count patches with [ landcover = "no-land" ]/ land-area) * 100)
  show conifers + evergreen + schrubland + waterfield ;; Last check all OK ;
end

to tickers ; lists set for time finishing at 150 years
   set drought-list (list 20 40 60 80 100 120 140)
   set short-conifer (list 1 15 30 45 60 75 90 105 120 135 150)
   set short-evergreen (list 1 50 100 150)
   set long-conifer (list 1 80 140)
   set long-evergreen (list 1 100)
   set rc-bwater (list 45 44 43 42 41 40 40 39 38 37 36 35)
   set re-bwater (list 20 19 18 17 16 15)
end

to go
  ; reset-ticks --> THIS WAS THE PROBLEM, IF ON NOT RUNNING
  ;; stop model if conifers and evergreen are all brown
  if ( dry-forests = 100 ) [
    stop ]
  ;; commands
  distribute-age
  experience-drought
  change-blue-water
  update-landcover
  initiate-management
  update-ha
  ;update-plots // taken out for model efficiency
  tick
end

;; distribute different ages and convert land depending on the age

to distribute-age
   ask patches [
   ;; grow 1 every tick
   set age age + 1
   ]
end

to experience-drought

  ask patches [
  if ( age > 150 ) and ( precipitation > 500 ) and ( ( landcover = "conifers" ) or ( landcover = "evergreen" ) ) [
      let dice random 6
      if dice = 0 [ set pcolor brown ]
      if dice = 1 [ set landcover "schrubland"
                    set drought 1 ]
      if dice > 1 [ set age 10 ]
    ]

  if ( age > 150 ) and ( precipitation < 500 ) and ( precipitation > 450 ) and ( ( landcover = "conifers" ) or ( landcover = "evergreen" ) ) [
      let dice random 5
      if dice = 0 [ set pcolor brown ]
      if dice = 1 [ set drought 1
                    set landcover "schrubland" ] ; ideally: set landcover = "schrubland"
      if dice > 1 [ set age 10 ]
    ]

  if ( age > 150 ) and ( precipitation < 450 ) and ( ( landcover = "conifers" ) or ( landcover = "evergreen" ) ) [
      let dice random 4
      if dice = 0 [ set pcolor brown ]
      if dice = 1 [ set landcover "schrubland"
                    set drought 1 ] ; ideally: set landcover = "schrubland"
      if dice > 1 [ set age 10 ]
    ]
  ]
end

to change-blue-water

  ifelse climate-change
      [ set precipitation ( precipitation - 1.15 )
        set ET-conifer ( ET-conifer + 0.03 )
        set ET-evergreen ( ET-evergreen + 0.03 ) ] ; amount said to decrease each year due to climate change
      [ ] ; it never changes...

  ask patches with [ landcover = "conifers" and managed = "No" ] [
    set bwater ( 100 - ET-conifer ) ]
  ask patches with [ landcover = "evergreen" and managed = "No" ] [
    set bwater ( 100 - ET-evergreen ) ]
end

to add-land-use

  ask patches [ set land-use 0 ] ; 0 = only forestry

  ask patches with [pycor < 75] [   ; southern coordinates
    ifelse agriculture-too?
      [ set land-use 1] ; 1 = forestry and agriculture
      [ set land-use 0] ; 0 = forestry
    ]
end

to update-landcover

  set bwater-conifer mean [bwater] of patches with [ landcover = "conifers" ]
  set bwater-evergreen mean [bwater] of patches with [ landcover = "evergreen" ]

  set forest-mass (count patches with [ landcover = "conifers" ] +
                   count patches with [ landcover = "evergreen" ] +
                   count patches with [ landcover = "schrubland" ])

  set dry-conifers ( count patches with [ pcolor = brown and landcover = "conifers" ]
    / forest-mass ) * 100 ;/ count patches with [ landcover = "conifers" ] ) * 100
  set dry-evergreen ( count patches with [ pcolor = brown and landcover = "evergreen" ]
    / forest-mass ) * 100 ;/ count patches with [ landcover = "evergreen" ] ) * 100
  set dry-schrubland ( count patches with [ drought = 1 and landcover = "schrubland" ]
    / forest-mass ) * 100
  set dry-forests (( dry-conifers + dry-evergreen ) / 2 )
end

; ##############################################################################################################
; SOCIAL SUBMODEL
; Set number of forest owners in the interface

;; Create breeds based on the numbers and percentages in the interface

to add-owners
  ask patches [
    if pcolor != black and pcolor != 88 [ set belong-to nobody ]
  ]

  create-traditionalists (number-owners * (tradi / 100)) [
    set color 15
    set shape "dot"
    set size 10 ]
  ask traditionalists [
    move-to one-of patches with [ belong-to = nobody ]
    pd
    set territory patches in-radius (random 30) with [ belong-to = nobody ]
    ask territory [
      set belong-to "traditionalists"
      set id-owner myself
    ]
   ]

  create-multifunctionalists (number-owners * (multi / 100)) [
    set color 25
    set shape "dot"
    set size 10 ]
  ask multifunctionalists [
    move-to one-of patches with [ belong-to = nobody ]
    pd
    set territory patches in-radius (random 30) with [ belong-to = nobody ]
    ask territory [
      set belong-to "multifunctionalists"
      set id-owner myself
    ]
   ]

  create-environmentalists (number-owners * (envir / 100)) [
    set color 45
    set shape "dot"
    set size 10 ]
  ask environmentalists [
    move-to one-of patches with [ belong-to = nobody ]
    pd
    set territory patches in-radius (random 30) with [ belong-to = nobody ]
    ask territory [
      set belong-to "environmentalists"
      set id-owner myself
    ]
   ]

  create-passives (number-owners * (passi / 100)) [
    set color 125
    set shape "dot"
    set size 10 ]
  ask passives [
    carefully [ move-to one-of patches with [ belong-to = nobody ] ] [ user-message "Please, create world and add owners again" ]
    pd
    set territory patches in-radius (random 30) with [ belong-to = nobody ]
    ask territory [
      set belong-to "passives"
      set id-owner myself
    ]

   ; if any? patches in-radius 25 with [ belong-to = nobody ]
    ;   [ set territory patches in-radius 20 with [ belong-to = nobody ]
     ;    ask territory [
      ;       set belong-to "passives"
       ;      set id-owner myself ]]
   ]

  if maxim + optim + tradi + passi + multi + envir != 100 [ user-message "Please, make sure forest owners categories sum up to 100%" stop ]
end

to distribute-management-plans

  ask n-of ((num-of-plans / 100) * ha-tradi-total) patches with [belong-to = "traditionalists"] [ set management-plan 1 ]
  ask n-of ((num-of-plans / 100) * ha-multi-total) patches with [belong-to = "multifunctionalists"] [ set management-plan 1 ]
  ask n-of ((num-of-plans / 100) * ha-envir-total) patches with [belong-to = "environmentalists"] [ set management-plan 1 ]
  ask n-of ((num-of-plans / 100) * ha-passi-total) patches with [belong-to = "passives"] [ set management-plan 1 ]
end

; ##############################################################################################################
; POLICY SUBMODEL
; Each identity respondets differently to the policy design

to initiate-management

  if ( dry-forests = 100 ) [
    stop ]

  ask patches with-max [age] [
  ; Multifunctionlists
  ; If below cost or more ES are on = 50 years, otherwise 15 years
    (ifelse Below-cost-coverage? [ ]; [ ask territory [ manage-long-multi ] ]
            Additional-ES-goal? [ manage-long-multi ] ;[ ask territory [ manage-long-multi ] ]
            One-time-payment? [ manage-long-multi ]
            ; else command
            [ manage-multi ] )

  ; Environmentalists
  ; If below cost or more ES or no intermediary are on = 50 years, otherwise 15 years
    ifelse No-intermediary?
      [ ]
      [ (ifelse  Below-cost-coverage? [ ]
                 Additional-ES-goal? [ manage-long-envir ]
                 One-time-payment? [ manage-long-envir ]
                ; else command
                [ manage-envir ] )
     ]

  ; Traditionalists
  ; Follows neighbours unless 1 x payment = stops after 3 times
    if any? neighbors in-radius 5 with [ managed = "Yes" and belong-to != "traditionalists" ] [
       manage-tradi ] ; Traditionalists manage if neighbors do

 ; Passives
 ; No management unless MP = 1 and below-cost is off
    ifelse Below-cost-coverage?                     ; If the switch is on, comparison is true and the turtle will run the commands inside the first set of bracket
      [ ]
      [ manage-passi ]
  ]
end

; For speed reasons

; MULTI-FUNCTIONALISTS

to manage-multi
  ; conifers can be "managed" every 15-20 years / evergreens every 100 (Informe DEMORGEST)
  ; old conifers are cut and new are planted (every 50 years), 30% following "Baronia Balanc Hidric"
  ;if ticks mod 15 = 0 [ --> not working
  if member? ticks short-conifer [
    ask n-of ( random 2 ) conifer-multi [ ; random 2 = 1, but just in case it wants to be increased
    set age 10
    set bwater random (46 - 35 + 1) + 35 ; between 0-10% gain
    set drought 0
    set managed "Yes"
    set landcover "conifers"
    set pcolor 67 ]
  ]
  ; old evergreens are cut and new are planted (every 100 years)
  if member? ticks short-evergreen [
    ask n-of ( random 2 ) evergreen-multi [
    set age 10
    set bwater random (21 - 15 + 1) + 15 ; between 0-5%
    set drought 0
    set managed "Yes"
    set landcover "evergreen"
    set pcolor 67 ]
    ]
end

to manage-long-multi
  if member? ticks long-conifer [
    ask n-of ( random 2 ) conifer-multi [
    set age 10 + 1
    set bwater random (46 - 35 + 1) + 35 ; between 0-10%
    set drought 0
    set managed "Yes"
    set landcover "conifers"
    set pcolor 67 ]
    ]
  if member? ticks long-evergreen [
    ask n-of ( random 2 ) evergreen-multi [
    set age 10 + 1
    set bwater random (21 - 15 + 1) + 15 ; between 0-5%
    set drought 0
    set managed "Yes"
    set landcover "evergreen"
    set pcolor 67 ]
    ]
end

; ENVIRONMENTALISTS

to manage-envir
  if member? ticks short-conifer [
    ask n-of ( random 2 ) conifer-envir [
    set age 10
    set bwater random (46 - 35 + 1) + 35 ; between 0-10% gain
    set drought 0
    set managed "Yes"
    set landcover "conifers"
    set pcolor 67 ]
    ]
  if member? ticks short-evergreen [
    ask n-of ( random 2 ) evergreen-envir [
    set age 10
    set bwater random (21 - 15 + 1) + 15 ; between 0-5%
    set drought 0
    set managed "Yes"
    set landcover "evergreen"
    set pcolor 67 ]
    ]
end

to manage-long-envir
  if member? ticks long-conifer [
    ask n-of ( random 2 ) conifer-envir [
    set age 10 + 1
    set bwater random (46 - 35 + 1) + 35 ; between 0-10%
    set drought 0
    set managed "Yes"
    set landcover "conifers"
    set pcolor 67 ]
    ]
  if member? ticks long-evergreen [
    ask n-of ( random 2 ) evergreen-envir [
    set age 10 + 1
    set bwater random (21 - 15 + 1) + 15 ; between 0-5%
    set drought 0
    set managed "Yes"
    set landcover "evergreen"
    set pcolor 67 ]
    ]
end

; TRADITIONALISTS

to manage-tradi
   if member? ticks short-conifer [
    ask n-of ( random 2 ) conifer-tradi [
    set age 10
    set bwater random (46 - 35 + 1) + 35 ; between 0-10% gain
    set drought 0
    set managed "Yes"
    set landcover "conifers"
    set pcolor 67 ]
    ]
  ; old evergreens are cut and new are planted (every 100 years)
  if member? ticks short-evergreen [
    ask n-of ( random 2 ) evergreen-tradi [
    set age 10
    set bwater random (21 - 15 + 1) + 15 ; between 0-5%
    set drought 0
    set managed "Yes"
    set landcover "evergreen"
    set pcolor 67 ]
    ]
end

to manage-long-tradi
  if member? ticks long-conifer [
    ask n-of ( random 2 ) conifer-tradi [
    set age 10 + 1
    set bwater random (46 - 35 + 1) + 35 ; between 0-10%
    set drought 0
    set managed "Yes"
    set landcover "conifers"
    set pcolor 67 ]
    ]
  if member? ticks long-evergreen [
    ask n-of ( random 2 ) evergreen-tradi [
    set age 10 + 1
    set bwater random (21 - 15 + 1) + 15 ; between 0-5%
    set drought 0
    set managed "Yes"
    set landcover "evergreen"
    set pcolor 67 ]
    ]
end

; PASSIVES

to manage-passi
  if member? ticks long-conifer [
    ask n-of ( random 2 ) conifer-passi [
    if management-plan = 1 [
    set age 10
    set bwater random (46 - 35 + 1) + 35 ; between 0-10%
    set drought 0
    set managed "Yes"
    set landcover "conifers"
    set pcolor 67 ] ]
    ]
  if member? ticks long-evergreen [
    ask n-of ( random 2 ) evergreen-passi [
    if management-plan = 1 [
    set age 10
    set bwater random (21 - 15 + 1) + 15 ; between 0-5%
    set drought 0
    set managed "Yes"
    set landcover "evergreen"
    set pcolor 67 ] ]
    ]
end

; OUTPUT

to update-ha

   set ha-multi ( count patches with [ managed = "Yes" and belong-to = "multifunctionalists" ] )
   set multi-per ( ha-multi / ha-multi-total ) * 100
   set multi-ha ( ha-multi * 0.01 )

   set ha-envir ( count patches with [ managed = "Yes" and belong-to = "environmentalists" ] )
   set envir-per ( ha-envir / ha-envir-total ) * 100
   set envir-ha ( ha-envir * 0.01 )

   set ha-tradi ( count patches with [ managed = "Yes" and belong-to = "traditionalists" ] )
   set tradi-per ( ha-tradi / ha-tradi-total ) * 100
   set tradi-ha ( ha-tradi * 0.01 )

   set ha-passi ( count patches with [ managed = "Yes" and belong-to = "passives" ] )
   set passi-per ( ha-passi / ha-passi-total ) * 100
   set passi-ha ( ha-passi * 0.01 )
end



;; see: https://stackoverflow.com/questions/38619289/storing-recalling-the-value-of-a-variable-in-netlogo

There is only one version of this model, created 2 months ago by Eulalia Baulenas.

Attached files

File Type Description Last updated
mcsc_raster.asc extension GIS map (required to run the model) about 1 month ago, by Eulalia Baulenas Download
SESPES: socio-ecological systems and payment for ecosystem services model.png preview Preview for 'SESPES: socio-ecological systems and payment for ecosystem services model' 2 months ago, by Eulalia Baulenas Download

This model does not have any ancestors.

This model does not have any descendants.
