Mumbai-Dabbawala-Main

extensions [ ls ]

globals
[
  grid-x-inc         ;; the amount of patches in between two roads in the x direction
  grid-y-inc         ;; the amount of patches in between two roads in the y direction
  roads              ;; agentset containing the patches that are roads
  station-1          ;; refers to a station at one end of a railway line user creates
  station-2          ;; refers to a station at another end of a railway line user creates
  names              ;; list contaning the names of stations
  collect-model-A    ;; for referencing the collect model at station-A
  collect-model-B    ;; for referencing the collect model at station-B
  collect-model-C    ;; for referencing the collect model at station-C
  deliver-model-D    ;; for referencing the deliver model at station-D
]

breed [ trains train ]
breed [stations station ]

stations-own [ name tiffins-with-me collect? next-opt-dest can-load? finished-collect?]
trains-own [ train-start train-dest tiffins-in-train moving? loaded? pick-up drop-off ]

;;;;;;;;;;;;;;;;;;;;;;
;; Setup Procedures ;;
;;;;;;;;;;;;;;;;;;;;;;

;; Initialize the display by giving the global and patch variables initial values

to setup
  ls:reset ; reset LevelSpace
  clear-all
  setup-globals
  setup-ls
  setup-roads
  setup-stations
  setup-railway
  reset-ticks
end

;; Initialize the necessary global variables to appropriate values

to setup-globals
  set grid-x-inc world-width / 10
  set grid-y-inc world-height / 10
  set names  [ "Station-A" "Station-B" "Station-C" "Station-D"]
  set deliver-model-D 3
end

;; Setup levelspace child models for stations at collection area

to setup-ls
  ;; create interactive levelspace child models for stations at collection area
  ls:create-interactive-models 1 "collect.nlogo"
  set collect-model-A last ls:models
  ls:create-interactive-models 1 "collect.nlogo"
  set collect-model-B last ls:models
  ls:create-interactive-models 1 "collect.nlogo"
  set collect-model-C last ls:models

  ls:let dw-capacity capacity                                      ;; the maximum number of tiffins each dabbawala can carry
  ls:let tiffins-count-per-area tiffins-count-per-area             ;; number of tiffins near each collection station
  ls:let collect-strategies collect-strategies                     ;; strategy used by the dabbawala to collect tiffins

  ;; setup levelspace childmodels for stations at collection area and initialize
  ls:ask collect-model-A [ setup "Station-A" dw-capacity tiffins-count-per-area collect-strategies]
  ls:ask collect-model-B [ setup "Station-B" dw-capacity tiffins-count-per-area collect-strategies]
  ls:ask collect-model-C [ setup "Station-C" dw-capacity tiffins-count-per-area collect-strategies]
end

to setup-roads
  ;; initialize the patch-owned variables and color the patches to a base-color
  ask patches
  [
    set pcolor brown
    if random 100 < 70
    [ set pcolor grey - 1 ]
    if random 100 < 20
    [ set pcolor green - 1 ]
  ]
  ;; initialize the global variables that hold patch agentsets
  set roads patches with
    [(floor((pxcor + max-pxcor - floor(grid-x-inc - 1)) mod grid-x-inc) = 0) or
    (floor((pycor + max-pycor) mod grid-y-inc) = 0)]
  ask roads [ set pcolor black ]
end

to setup-stations
  create-stations 4 [
    let xy one-of patches with [ pxcor != [pxcor] of roads
      and pycor != [pycor] of roads
      and count stations in-radius 20 = 0 ]
    setxy [pxcor] of xy [pycor] of xy
    set shape "house two story"
    set size 5
    set name item who names
    ifelse name = "Station-D"
    [ set collect? False              ;; Station-D is at the distribution area
      set can-load? True
      set finished-collect? True ]
    [ set collect? True               ;; Other stations are at the collection area
      set can-load? False
      set finished-collect? False ]
    set label name
    set tiffins-with-me []
    set next-opt-dest 0
  ]
end

to setup-railway
  ask stations [
    let next-station min-one-of (other stations) [ distance myself ]        ;; choosing closest station as next-station
    if link-neighbor? next-station
    [ set next-station max-one-of (other stations) [ distance myself ]]
    create-link-with next-station [ set shape "rail" ]                      ;; Create rail-line between two stations
    ask patch-here [
      sprout 1 [
        set breed trains
        set shape "train passenger car"
        set size 4
        set train-start one-of stations-here
        set train-dest next-station
        set moving? False
        set loaded? False
        set tiffins-in-train []
  ]]]
end

to select-station-1
  if mouse-down? [
    set station-1 stations with [ round xcor = round mouse-xcor and round ycor = round mouse-ycor ]
    if any? station-1 [stop]
  ]
end

to select-station-2
  if mouse-down? [
    set station-2 stations with [ round xcor = round mouse-xcor and round ycor = round mouse-ycor  ]
    if station-2 != nobody and station-1 != nobody [
      ask station-2 [
        ifelse not link-neighbor? one-of station-1 [
          create-link-with one-of station-1 [ set shape "rail" ]
          ask patch-here [
            sprout 1 [
              set breed trains
              set size 4
              set shape "train passenger car"
              set train-start one-of station-2
              set train-dest one-of station-1
              set loaded? False
              set tiffins-in-train []
              set moving? False ]]]
        [
          ask link one-of [ who ] of station-1 one-of [ who ] of station-2 [ die]
            ask trains with [ (train-start = one-of station-2 and train-dest = one-of station-1)
            or (train-start = one-of station-1 and train-dest = one-of station-2) ]
            [ die ]
          ]
      ]
      set station-1 nobody
      set station-2 nobody
      stop ]
  ]
end

to go
  ask stations
  [ set label (word name ": " length tiffins-with-me) ]
  find-path-to-dest
  run-train
  load-tiffins-in-train
  ask trains with [loaded?]
  [
    drop-tiffins-at-station
  ]

  ;; Run collect-model-A
  if ls:model-exists? collect-model-A
  [
    ls:ask collect-model-A [go]
    if [done?] ls:of collect-model-A
    [
      output-show "Station-A"
      output-show ( word "Collected: " length [ tiffins-dest-list ] ls:of collect-model-A )
      output-show ( word "Gap: " [delay] ls:of collect-model-A )
      output-show ( word "Time taken to collect: " [time-taken] ls:of collect-model-A )
      update-tiffins-at-station-A
    ]
  ]

  ;; Run collect-model-B
  if ls:model-exists? collect-model-B
  [
    ls:ask collect-model-B [go]
    if [done?] ls:of collect-model-B
    [
      output-show "Station-B"
      output-show ( word "Collected: " length [ tiffins-dest-list ] ls:of collect-model-B )
      output-show ( word "Gap: " [delay] ls:of collect-model-B )
      output-show ( word "Time taken to collect: " [time-taken] ls:of collect-model-B )
      update-tiffins-at-station-B
    ]
  ]

  ;; Run collect-model-C
  if ls:model-exists? collect-model-C
  [
    ls:ask collect-model-C [go]
    if [done?] ls:of collect-model-C
    [
      output-show "Station-C"
      output-show ( word "Collected: " length [ tiffins-dest-list ] ls:of collect-model-C )
      output-show ( word "Gap: " [delay] ls:of collect-model-C)
      output-show ( word "Time taken to collect: " [time-taken] ls:of collect-model-C )
      update-tiffins-at-station-C
    ]
  ]

  ;; Run deliver-model-D
  ifelse ls:model-exists? deliver-model-D
  [
    ls:ask deliver-model-D [go]
    if [done?] ls:of deliver-model-D
    [
      output-show ( word "Delivered: " [ count tiffins with [ not hidden? ]] ls:of deliver-model-D )
      output-show ( word "Gap: " [delay] ls:of deliver-model-D)
      output-show ( word "Time taken to deliver: " [time-taken] ls:of deliver-model-D )
      ls:close deliver-model-D
      stop
    ]
  ]
  [
    if count stations with [ collect? and can-load? and length tiffins-with-me = 0 ] = 3 and count trains with [ length tiffins-in-train > 0 ] = 0
    [
      setup-child-model-deliver
    ]
  ]
  tick
end

;;;;;;;;;;;;;;;;;;;;;;
;;   Go Procedures  ;;
;;;;;;;;;;;;;;;;;;;;;;

to find-path-to-dest
  ask stations with [collect?]
  [
    let adj-stations in-link-neighbors
    set next-opt-dest min-one-of adj-stations [ distance one-of stations with [ name = "Station-D" ]]
    if finished-collect?
    [
      let prev-station stations with [ next-opt-dest = myself ]
      ifelse one-of prev-station != nobody
      [
        if not any? prev-station with [not can-load?]
        [ set can-load? True ]
      ]
      [ set can-load? True ]
    ]
  ]
end

to update-tiffins-at-station-A
  ask stations with [ name = "Station-A" ]
  [
    ifelse tiffins-with-me = []
    [ set tiffins-with-me [ tiffins-dest-list ] ls:of collect-model-A ]
    [
      foreach [ tiffins-dest-list ] ls:of collect-model-A [ x -> set tiffins-with-me  lput x tiffins-with-me ]
    ]
    set finished-collect? True
    ls:close collect-model-A
  ]
end

to update-tiffins-at-station-B
  ask stations with [ name = "Station-B" ]
  [
    ifelse tiffins-with-me = []
    [ set tiffins-with-me [ tiffins-dest-list ] ls:of collect-model-B ]
    [
      foreach [ tiffins-dest-list ] ls:of collect-model-B [ x -> set tiffins-with-me  lput x tiffins-with-me ]
    ]
    set finished-collect? True
    ls:close collect-model-B
  ]
end

to update-tiffins-at-station-C
  ask stations with [ name = "Station-C" ]
  [
    ifelse tiffins-with-me = []
    [ set tiffins-with-me [ tiffins-dest-list ] ls:of collect-model-C ]
    [ foreach [ tiffins-dest-list ] ls:of collect-model-C [ x -> set tiffins-with-me  lput x tiffins-with-me ]
    ]
    set finished-collect? True
    ls:close collect-model-C
  ]
end

to load-tiffins-in-train
  ask stations with [ collect? and can-load? ]
  [
    let pref-train trains-here with [ train-start = myself and train-dest = [ next-opt-dest ] of myself ]
    if any? pref-train and tiffins-with-me != []
    [
      ask one-of pref-train
      [
        set pick-up train-start
        set drop-off train-dest
        ifelse tiffins-in-train = []
        [
          set tiffins-in-train [ tiffins-with-me ] of myself
        ]
        [
          foreach [ tiffins-with-me ] of myself [ x -> set tiffins-in-train lput x tiffins-in-train ]
        ]
        set loaded? True
        set label length tiffins-in-train
      ]
      set tiffins-with-me []
    ]
  ]
end

to setup-child-model-deliver
  ls:create-interactive-models 1 "deliver.nlogo"
  set deliver-model-D last ls:models
  ls:let dw-capacity capacity
  ls:let tiffins-to-deliver length  [tiffins-with-me] of station 3
  ls:let main-delivery-cors [tiffins-with-me] of station 3
  ls:let delivery-strategies delivery-strategies
  output-show (word "Total lunchboxes to deliver: " length [tiffins-with-me] of station 3 )
  ls:ask deliver-model-D [ setup "Station-D" dw-capacity tiffins-to-deliver main-delivery-cors delivery-strategies ]
end

to run-train
  ask trains
  [
    if ticks mod ( 150 + random 50 ) = 0 or moving?
    [
      set moving? True
      if moving?
      [
        face train-dest ;; not strictly necessary, but improves the visuals a bit
        fd 0.5
        if one-of stations-here = train-dest
        [
          set moving? False
          let temp train-dest
          set train-dest train-start
          set train-start temp
        ]
      ]
    ]
  ]
end

to drop-tiffins-at-station
  let drop-station stations-here with [ name = [[ name ] of drop-off ] of myself ]
  if any? drop-station
  [
    ask one-of drop-station
    [
      ifelse tiffins-with-me = []
      [ set tiffins-with-me [ tiffins-in-train ] of myself ]
      [ foreach [ tiffins-in-train ] of myself [ x -> set tiffins-with-me lput x tiffins-with-me ]]
      ]
    set tiffins-in-train []
    set loaded? False
    set label length tiffins-in-train
  ]
end
