; An example of Genetic Expression Programming in NetLogo
;
; Author:   jihe.Gao@jiejiaotech.com
;
; ------------------------------------------------------------------------------------------
extensions [csv table time]

breed [ Stocks stock ]
breed [ Investors investor ]
breed [ genes gene ]
breed [ codeturtles codeturtle ]

globals [
  gp_weighted_gene_list
  gp_syntaxlist
  gp_generation
  avgfitness
  bestfitness
  worstfitness
  gp_best_fitness_this_gen
  the_watched_one
]


genes-own
[
  c_type
  input_var_list
  output_type  ; void (command), reporter, boolean
  odds
]

codeturtles-own
[
  my_code
  my_tree
  gp_raw_fitness
  birthtime
  result
]

to setup
  clear-all
  reset-ticks
  gp-setup
end




;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;
;;                   START OF GP LIBRARY CODE                         ;;
;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;
;;      gpuser-setup-syntax    (determines the ingredients for randomlly generated code trees)
;;      gpuser-run-codeturtles  (determines what happens to the codeturtles during a generation)
;;      gpuser-initialize-codeturtle  (run when each codeturtle that is created, sets initial variables, etc)
;;      gpuser-calculate-raw-fitness   (reports some measure analogous to "distance to goal", where 0 is perfection)
;;      gpuser-calculate-adjusted-fitness (reports a value between 0 and 1, where 1 is perfection)
;;
;; In addition, your setup should call "gp-setup" and your go should call "gp-episode"
;;
;; Notes
;;
;;  Structure of a tree node:
;;    ["NODE_VALUE"  RTYPE_*  TYPE_*  CHILD1  CHILD2  ... ]
;;

to-report gp-target-answer
  report ticks * 3
end

to gp-setup
  gp-setup-genes
  gp-setup-codeturtles
end

to gp-setup-genes
  ;set gp_syntaxlist csv:from-file "genes.csv"
  set gp_syntaxlist init-gp-syntaxlist
  foreach gp_syntaxlist [ [?]->
    if not any? turtles with [label = first ?][
      create-genes 1 [
        ;["gp_if" "TYPE_COMMAND" "RTYPE_BOOLEAN" "RTYPE_COMMAND" 10]
        set label first ?
        set input_var_list sublist ? 2 (length ? - 1)
        set output_type item 1 ?
        set odds last ?
        move-to one-of patches with [pycor = min-pycor]
      ]
    ]
  ]
  set gp_weighted_gene_list (reduce [[?1 ?2]-> (sentence ?1 ?2)] (map [[?]-> n-values ([odds] of ?) [[label] of ?] ] sort genes))
end

to gp-setup-codeturtles
  create-codeturtles population-size [ gp-initialize-codeturtle [0]]
end


;; whenever codeturtles are created (at the beginning of each generation) this procedure is run
;; gen_config: (list [my_code] of winner [my_code] of partner )

to gp-initialize-codeturtle [gene_lists]
  ifelse gene_lists = [0]
  [
    set my_code (gp-weighted-random-genes initial-chromosome-length)
  ]
  [
    set my_code (gp-cross-chromosomes gene_lists)
  ]
  carefully [
    set my_tree gp-compile-tree (sublist my_code (1 + position "Q" my_code) length my_code)
  ][set my_tree "0"]
  set birthtime ticks
  set size 2
  set shape "circle"
  set gp_raw_fitness 100  ; large number (very unfit)
  set xcor random-xcor ; find the start patch
end


;; reports a random entry from a syntaxlist, where the chance of an entry being chosen
;;  is weighted by the number that is the last entry of the element

to-report gp-weighted-random-genes [ length_gene ]
  report fput "Q" n-of length_gene gp_weighted_gene_list
end

to-report gp-cross-chromosomes [DNA_lists]
  let DNA0 first DNA_lists
  let DNA1 last  DNA_lists
  ifelse length DNA0 < length DNA1
  [ set DNA1 sublist DNA1 0 (1 + length DNA0) ]
  [ if length DNA0 > length DNA1 [
    set DNA1 (sentence DNA1 n-values (length DNA0 - length DNA1) ["0"]) ]
  ]
  let dna []
  (foreach DNA0 DNA1 [ [d1 d2]->
    ifelse (random 100 < crossover-chance)
    [ set dna lput d2 dna ]
    [
      ifelse (random 100 < mutate-chance)
      [ set dna lput (one-of gp_weighted_gene_list) dna ]
      [ set dna lput d1 dna ]]
  ])
  report dna
end


;;

to-report gp-compile-tree [this_code]
  ; this_code : [ "gp_+" "3" "8" "32" "0" ]

  let thegene one-of turtles with [label = first this_code]
  set this_code but-first this_code
  let tree reduce [[?1 ?2]-> (word ?1 " " ?2)] [(sentence label input_var_list)] of thegene

  while [not empty? this_code and member? "R" tree][
    set thegene one-of turtles with [label = first this_code]
    set this_code but-first this_code
    let index position "R" tree
    set tree replace-item index tree (insert-node-string thegene)
  ]
  report tree
end

to-report insert-node-string [thegene]
  report reduce [[?1 ?2]-> (word " " ?1 " " ?2 " ")] [(sentence label map [[?]-> (word "(" ? ")")] input_var_list)] of thegene
end







;; This is the main "go" procedure for the gp-library.

to gp-episode
  gp-create-next-generation ; breed_option = "wta" "equal"
  gp-run-codeturtles
  gp-update-fitness
  if move? [ask codeturtles [set ycor min-pycor + gp-fitness * world-height - 1]]
  gp-plot
  tick
end



;; codeturtles procedure
;; Think of this reporter as "how far am I from my goal?"
;; Thus, a perfect codeturtle has a raw fitness of 0
;;       a bad codeturtle has an arbitrarily large raw fitness

to gp-run-codeturtles
  ask codeturtles [carefully [set result (runresult my_tree)][die]]
end

to gp-update-fitness
  ask codeturtles [
    set gp_raw_fitness gp-calculate-fitness
  ]
end

; user-defined fitness function ( cost function )

to-report gp-calculate-fitness
  report abs (gp-target-answer - result)
end

to-report gp-fitness
  report 1 / (1 + gp_raw_fitness)
end

to gp-create-next-generation

  if breed_option = "wta" ; winner takes all
  [
    let winner min-one-of codeturtles [gp_raw_fitness]
    repeat population-size - count turtles [
      let partner one-of codeturtles
      gp-breed-new-codeturtle (list gp_generation [my_code] of winner [my_code] of partner ) ]
  ]
  if breed_option = "equal"
  [
    repeat population-size - count turtles [
      let couple n-of 2 codeturtles with [gp-fitness >= avgfitness]
      if couple = nobody [set couple n-of 2 codeturtles]
      gp-breed-new-codeturtle (list [my_code] of first sort couple [my_code] of last sort couple) ]
  ]

if count codeturtles > n-die-out-each-tick [ ask n-of n-die-out-each-tick codeturtles [ die ] ]
end


; gen_config: (list [my_code] of turtle1 [my_code] of turtle2 )

to gp-breed-new-codeturtle [gene_lists]
  create-codeturtles 1 [ gp-initialize-codeturtle gene_lists ]
end







;; plot the fitnesses of the current generation, and update the gp-best-fitness-this-gen variable

to gp-plot
  if any? codeturtles [
    set bestfitness max [ gp-fitness ] of codeturtles
    set avgfitness mean [ gp-fitness ] of codeturtles
    set worstfitness min [ gp-fitness ] of codeturtles
    set gp_best_fitness_this_gen bestfitness

    set-current-plot "Fitness Plot"
    set-current-plot-pen "avg"
    plot avgfitness
    set-current-plot-pen "best"
    plot bestfitness
    set-current-plot-pen "worst"
    plot worstfitness
  ]
end



;; displays the code of the best-this-gen codeturtle in the output box

to gp-showbest
  clear-output
  ask one-of (codeturtles with-min [ gp_raw_fitness ])
  [ print (word self " tree: " my_tree " result: " result )]
end

to gp-show-all
  ;clear-output
  foreach sort-by [[?1 ?2]-> [gp_raw_fitness] of ?1 < [gp_raw_fitness] of ?2] codeturtles
  [
    [?]-> ask ? [
      show (word self " code: " my_code " tree: " my_tree " result: " result )
    ]
  ]
end

to select-one
  if mouse-down? [
    set the_watched_one closest-codeturtle mouse-xcor mouse-ycor turtles with [breed != links]
    ask links [die]
    ask turtles with [shape = "square"][die]
    ask codeturtles [set label ""]
    watch the_watched_one
    ask the_watched_one [
      set label my_tree
      setxy mouse-xcor mouse-ycor
    ]
    display
  ]
end

to-report closest-codeturtle [x y agent-set]  ; Return closest agent to x, y
 report min-one-of codeturtles [distancexy x y]
end

to reset-codeturtles
end
;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;
;;                    END OF GP LIBRARY CODE                          ;;
;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;

;; These are atom genes of procedures and reporters, that help form the DNA of the codeturtles.

to-report init-gp-syntaxlist
report [
  ["gp_+"      "TYPE_OPERATOR" "R" "R" 10]
  ["gp_-"      "TYPE_OPERATOR" "R" "R" 10]
  ["gp_*"      "TYPE_OPERATOR" "R" "R" 5]
  ["gp_safediv" "TYPE_REPORTER" "R" "R" 5]
  ["gp_random"  "TYPE_REPORTER" "R" 10]
  ["gp_ticks"   "TYPE_REPORTER" 5]
  ["0" "TYPE_REPORTER" 20]
  ["1" "TYPE_REPORTER" 20]
  ["2" "TYPE_REPORTER" 20]
  ["3" "TYPE_REPORTER" 20]
  ["4" "TYPE_REPORTER" 20]
  ["5" "TYPE_REPORTER" 20]
  ["8" "TYPE_REPORTER" 20]
  ["16" "TYPE_REPORTER" 20]
  ["32" "TYPE_REPORTER" 20]
]
end

to-report gp_ticks
  report ticks
end

to-report gp_ifelse-value [bool tree1 tree2]
  report ifelse-value bool [ runresult tree1 ][ runresult tree2 ]
end

to-report gp_+ [input1 input2]
  report input1 + input2
end

to-report gp_- [input1 input2]
  report input1 - input2
end

to-report gp_* [input1 input2]
  report input1 * input2
end

to-report gp_safediv [input1 input2]
  report ifelse-value (input2 != 0) [input1 / input2][999999]
end

to-report gp_random [input]
  report random input
end

to-report gp_>= [input1 input2]
  report input1 >= input2
end

to-report gp_<= [input1 input2]
  report input1 <= input2
end

to-report gp_> [input1 input2]
  report input1 >= input2
end

to-report gp_< [input1 input2]
  report input1 >= input2
end
