Taskable volunteers 01

;;;;;;;;;;;;;;;;;;;;;;;;;;;
; globals and definitions ;
;;;;;;;;;;;;;;;;;;;;;;;;;;;

breed [reporters reporter]

breed [volunteers volunteer]
breed [issues issue]

; report is reserved word, so we'll use observation.
directed-link-breed [ observations observation ]
directed-link-breed [ v_tasks v_task ]

; two types of volunteers. One can be asigned a task, other can't
; the taskable ones also have a "base" and prefer to stay in its vicinity.
; In the future we could replace this with possibility to task them to search a certain area.
;
; *motivation* is percentage - at motivation >= 100%:
;   - taskable volunteer can be tasked to confirm observations.
;   - both types will report nearby issues
;
; the chance of taking the task/reporting findings depends on motivation (TODO!)

volunteers-own [ v_motivation xhome yhome ]
reporters-own  [ v_motivation ]

; i_resolved? is set to true when we have enough reports.
issues-own [ i_resolved? i_generated i_discovered i_resolved i_consensus]

; not sure what we need in this link...
observations-own [v_breed timestamp correct?]
;v_tasks-own []

;;;;;;;;;;;;;;;;;;;;
; setup procedures ;
;;;;;;;;;;;;;;;;;;;;

to setup
  clear-all
  setup-world
  setup-reporters
  setup-volunteers
  setup-issues
  reset-ticks
end


; initially all patches are just grey = unknown.

to setup-world
  resize-world 0 Size-world 0 Size-world
  set-patch-size 1000 / Size-world
  ask patches [
      set pcolor grey
  ]
end


; randomly add some spontaneous volunteers to the world

to setup-reporters
  set-default-shape reporters "person"
  ; can't happen with a slider
  ;  if not is-number? Nr-reporters [ set Nr-reporters 100 ]
  create-reporters Nr-reporters [
    setxy random-xcor random-ycor
    set v_motivation init-motivation
    set color blue
    set size 1
  ]
end

; randomly add some taskable volunteers to the world

to setup-volunteers
  set-default-shape volunteers "person"
  ;  if not is-number? Nr-taskable [ set Nr-taskable 10 ]
  create-volunteers Nr-taskable [
    setxy random-xcor random-ycor
    ; volunteers will try to stay near their home coordinates
    ; This could be considered kind of a task too.
    set xhome xcor
    set yhome ycor
    set v_motivation init-motivation
    set color violet
    set size 1
  ]
end


; randomly add some issues to the world
;
; issues have a generation time & later also a discovery time

to setup-issues
  set-default-shape issues "target"
  create-issues Nr-issues [
    setxy random-xcor random-ycor
    set i_generated 0
    set i_consensus 0
    set i_resolved? false
    set color red
    set size 1
  ]
end


;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;
; Procedures governing the world development ;
;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;

to go
  assign-tasks
  move-reporters
  move-volunteers
  report-issues
  manage-issues
  if count issues with [ i_resolved? = true ] = Nr-issues [ stop ]
  tick
end

; some volunters can be tasked, e.g. to quality-assure the reports

to assign-tasks
  ; nothing to do. Actually we should only call this function if there is something to do..
  ; Note: if I need 0 confirmation, this means one observation. 1 confirmations = 2 observations etc.
  ; So open issues are the ones with with less than Nconfirmations + 1 links. Which is the same as "<= Nconfirmations" links.
  let open_issues issues with [i_discovered > 0 and (count in-link-neighbors) <= Nr-confirmations]
  if count open_issues = 0 [stop]

  let free_volunteers volunteers with [not any? out-v_task-neighbors]
  ask free_volunteers [
    let nearest_issue min-one-of (issues with [
      i_discovered > 0
      and not in-observation-neighbor? myself
      and (count in-link-neighbors) <= Nr-confirmations
      and distance myself <= R-task ])  [distance myself ]
    if is-issue? nearest_issue [
      create-v_task-to nearest_issue [
        if show-tasks? [
          set color orange
        ]
      ]
      if debug? [
        write "created task"
        show self
      ]
      set color orange
      ;set size size + 1
    ]
  ]
  if Adjust-tasking-radius? [
    ; let's play with tasking radius
    let tasking-need count issues with [ i_discovered > 0 and (count in-link-neighbors) <= Nr-confirmations]
    let tasked-volunteers count v_tasks
    let tasking-offer Nr-taskable - tasked-volunteers

    ifelse  tasking-need < tasking-offer
      [ if tasking-need > 0 and R-task < max-pxcor [set R-task  R-task + 1 ] ]
      [ if tasking-offer = 0 and R-task > R-discover [set R-task  R-task - 1 ] ]
;      [ if tasking-offer > Nr-taskable / 10 + 1 and R-task < max-pxcor [set R-task  R-task + 1 ] ]
;      [ if tasking-need > 0 and R-task > R-discover [set R-task  R-task - 1 ] ]

  ]
end

; reporters just move at random.
; motivation always goes down, unless an issue is discovered

to move-reporters
  ask reporters [
    right random 360
    forward 1
    if v_motivation > 0 [
      set v_motivation v_motivation - 1
    ]
  ]
end

; tasked volunteers move towards their task or at random if no task defined.

to move-volunteers
  ask volunteers [
    ; current target?
    ; normally there should be only one, so "one-of" is the same as
    ; min-one-of (out-v_task-neighbors)  [distance myself ]

    ; If we have a task, let's go for it!
    ifelse any? out-v_task-neighbors [
;      print "heading towards"
;      print one-of out-v_task-neighbors
      face one-of out-v_task-neighbors
    ]
    ; else we'll stroll arround
    [
      ; if "with base" meander back towards vicinity of the initial position
      if with-base?
      [
        if distancexy xhome yhome > r-task / 4 [ facexy xhome yhome ]
      ]
      ; let him also menader a bit.
      right random 60 - 30
    ]
    forward 1
    ; motivation always goes down, unless an issue is discovered
    ; TODO: this is not implemented yet
    if v_motivation > 0 [
      set v_motivation v_motivation - 1
    ]
  ]
end

; report observations on nearby issues

to report-issues
  ask turtles with [is-reporter? self or is-volunteer? self ] [
    ; "myself" refers to a volunteer which initiated the loop, not to issue!
    ; issue would be reffered to as "self" in own context.
    let this_reporter self

    ; which issues are in vicinity?
    ask issues in-radius R-discover [
      ; report only those issues we haven't reported already!
      if in-observation-neighbor? myself [ stop ]

      ; delete the task from a caling turtle to this issue
      ask my-in-v_tasks with [ other-end = this_reporter ] [
        ask this_reporter [
          set color violet
          ]
        if debug? [
          write "deleting obsolete task (1):"
          print self
        ]
        die
      ]
      ; don't report if already enough reports.
      ; This is kind-or optional, results might even improve if we don't do this.
      ; Note: 0 confirmation means 1 observations etc.
      if (count in-observation-neighbors) > Nr-confirmations [stop]
      ; good reporters grow. :-)
      ask this_reporter [
        set size size + 1
      ]

      ; is our observation correct or not?
      let obs_correct? (error-perc < random 100)

      ; if issue is already discovered, confirm
      ifelse i_discovered > 0
      [
        create-observation-from myself [
          if show-observations? [
            ; actually i should set it to black if the observation is wrong...
            ifelse obs_correct? [set color green] [set color black]
          ]
          set v_breed [breed] of this_reporter
          set timestamp ticks
          set correct? obs_correct?
          if debug? [print self]
        ]
      ]
      ; else report new discoveries
      [
        set i_discovered ticks
        create-observation-from myself [
          if show-observations? [
            ifelse obs_correct? [set color red] [set color magenta]
          ]
          set v_breed [breed] of this_reporter
          set timestamp ticks
          set correct? obs_correct?
          if debug? [print self]
        ]
        set color orange
        set size 1.5
      ]
    ]
  ]
end

to manage-issues
  ; issues are considered resolved if we get enough reports on it.
  ; thus we can have "false positives" here too.

  ask issues with [ not i_resolved? and (count in-observation-neighbors) > Nr-confirmations ] [
    if debug? [
      write "No. neigbours:"
      print count in-observation-neighbors
    ]

    set i_resolved? true
    set i_resolved ticks
    ;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;
    set i_consensus (count my-in-observations with [correct?] - count my-in-observations with [ not correct? ])

    ; if needed, tell the volunteers that their help isn't needed anymore!
    ask my-in-v_tasks [
      if debug? [
        write "deleting obsolete tasks (2):"
        print self
      ]
      if is-volunteer? other-end [
        ask other-end [
          set color violet
          ;set size 1.5
        ]
      ]
      die
    ]
    ifelse i_consensus > 0
    [ set color turquoise ]
    [ set color black ]
    set size 2
  ]
end
