"Dynamic Project Aggregation"

breed [investors investor]

patches-own [
  favorability-level?         ;; indicates level of favorability for cell, -2 for unfavorable, -1 for
                              ;; less favorable, 0 for neutral, 1 for more favorable, 2 for favorable
  favorable-neighbors  ;; counts how many neighboring cells make a favorable match
near-patches
]

to setup
  clear-all
  ask patches
  ;; sets patch colors randomly ranging between 1-5
    [if distribution = "random" [ set pcolor ((random 5) + 102) ]
      if distribution = "normal" [set pcolor (round (random-normal 2.5 1) + 102)]
    ]
  ask patches
    [ set pcolor [pcolor] of one-of neighbors ]
  ask n-of num-turtles patches [ sprout 1 ]
  ask patches with [pcolor <= 102]
  [set favorability-level? -2]
  ask patches with [pcolor = 103]
  [set favorability-level? -1]
  ask patches with [pcolor = 104]
  [set favorability-level? 0]
  ask patches with [pcolor = 105]
  [set favorability-level? 1]
  ask patches with [pcolor >= 106]
  [set favorability-level? 2]
  ask turtles [set shape "tree" set color 45]
  reset-ticks
;  go
;  determine-competitors
;  neighbors-test
;  grow
;  do-plot
end

to go
  determine-competitors
  neighbors-test
  grow
  do-plot
  tick
end

to determine-competitors
  ask turtles [
    let competitors count turtles-on neighbors
    if competitors >= level-of-competition
    [die]
  ]
end

to neighbors-test ;; determining if neighbors are good for investment
;  repeat 10
;  [
    ask n-of 2 patches [
      let added-self [favorability-level?] of patch-at 0 0
      let added-east [favorability-level?] of patch-at 1 0
      let added-west [favorability-level?] of patch-at -1 0
      let added-north [favorability-level?] of patch-at 0 1
      let added-south [favorability-level?] of patch-at 0 -1
      let added-southeast [favorability-level?] of patch-at 1 -1
      let added-northeast [favorability-level?] of patch-at 1 1
      let added-southwest [favorability-level?] of patch-at -1 -1
      let added-northwest [favorability-level?] of patch-at -1 1

      if added-self + added-east >= favorability-need
      and
      (any? turtles-here)
      and
      added-self >= favorability-threshold [ask patch-at 1 0 [set pcolor 55 ] ]

      if added-self + added-west >= favorability-need
      and
      (any? turtles-here)
      and
      added-self >= favorability-threshold  [ask patch-at -1 0 [set pcolor 55 ] ]

      if added-self + added-north >= favorability-need
      and
      (any? turtles-here)
      and
      added-self >= favorability-threshold  [ask patch-at 0 1 [set pcolor 55 ] ]

      if added-self + added-south >= favorability-need
      and
      (any? turtles-here)
      and
      added-self >= favorability-threshold  [ask patch-at 0 -1 [set pcolor 55 ] ]

      if added-self + added-southeast >= favorability-need
      and
      (any? turtles-here)
      and
      added-self >= favorability-threshold [ask patch-at 1 -1 [set pcolor 55 ] ]

      if added-self + added-northeast >= favorability-need
      and
      (any? turtles-here)
      and
      added-self >= favorability-threshold [ask patch-at 1 1 [set pcolor 55 ] ]

      if added-self + added-southwest >= favorability-need
      and
      (any? turtles-here)
      and
      added-self >= favorability-threshold [ask patch-at -1 -1 [set pcolor 55 ] ]

      if added-self + added-northwest >= favorability-need
      and
      (any? turtles-here)
      and
      added-self >= favorability-threshold [ask patch-at -1 1 [set pcolor 55 ] ]

      if any? neighbors with [ pcolor = 55 ]
      and
      (any? turtles-here)
      and
      favorability-level? >= favorability-threshold
      [set pcolor 55]
    ]
;  ]
  ask turtles [
;    if one-of neighbors with [ pcolor = 55 ]
    if any? neighbors with [ pcolor = 55 ]
    and
    (any? turtles-here)
    and
    favorability-level? >= favorability-threshold
    [hatch-investors 1 [set color 105 set shape "tree"]]
    if any? investors-here [die]
  ]
end

to grow
;  repeat 5
;  [
    ask one-of patches [
   ask investors
    [
      ask patches in-radius investment-limit-radius
          [set near-patches 1]]

;      let near-patches patches in-radius investment-limit-radius

      if count neighbors with [ pcolor = 55 ] >= growth-capacity
      and
      favorability-level? >= favorability-threshold
      and
      near-patches = 1
      and
      [favorability-level?] of patch-at 1 0  >= favorability-threshold
      [ask patch-at 1 0 [set pcolor 55 ]]

      if count neighbors with [ pcolor = 55 ] >= growth-capacity
      and
      favorability-level? >= favorability-threshold
      and
      near-patches = 1
      and
      [favorability-level?] of patch-at -1 0  >= favorability-threshold
      [ask patch-at -1 0 [set pcolor 55 ]]

      if count neighbors with [ pcolor = 55 ] >= growth-capacity
      and
      favorability-level? >= favorability-threshold
      and
      near-patches = 1
      and
      [favorability-level?] of patch-at -1 -1  >= favorability-threshold
      [ask patch-at -1 -1 [set pcolor 55 ]]

      if count neighbors with [ pcolor = 55 ] >= growth-capacity
      and
      favorability-level? >= favorability-threshold
      and
      near-patches = 1
      and
      [favorability-level?] of patch-at 0 -1  >= favorability-threshold
      [ask patch-at 0 -1 [set pcolor 55 ]]

      if count neighbors with [ pcolor = 55 ] >= growth-capacity
      and
      favorability-level? >= favorability-threshold
      and
      near-patches = 1
      and
      [favorability-level?] of patch-at -1 -1  >= favorability-threshold
      [ask patch-at -1 -1 [set pcolor 55 ]]

      if count neighbors with [ pcolor = 55 ] >= growth-capacity
      and
      favorability-level? >= favorability-threshold
      and
      near-patches = 1
      and
      [favorability-level?] of patch-at 0 1  >= favorability-threshold
      [ask patch-at 0 1 [set pcolor 55 ]]

      if count neighbors with [ pcolor = 55 ] >= growth-capacity
      and
      favorability-level? >= favorability-threshold
      and
      near-patches = 1
      and
      [favorability-level?] of patch-at 1 1  >= favorability-threshold
      [ask patch-at 1 1 [set pcolor 55 ]]

      if count neighbors with [ pcolor = 55 ] >= growth-capacity
      and
      favorability-level? >= favorability-threshold
      and
      near-patches = 1
      and
      [favorability-level?] of patch-at 1 -1  >= favorability-threshold
      [ask patch-at 1 -1 [set pcolor 55 ]]

      if count neighbors with [ pcolor = 55 ] >= growth-capacity
      and
      favorability-level? >= favorability-threshold
      and
      near-patches = 1
      and
      [favorability-level?] of patch-at -1 1  >= favorability-threshold
      [ask patch-at -1 1 [set pcolor 55 ]]

;   ]
    ]
  do-plot
end

to do-plot
  let invested-patches [favorability-level?] of patches with [pcolor = 55]
  set-current-plot "Favorability Levels of Invested Parcels"
  set-current-plot-pen "parcels"
  histogram invested-patches
end

to-report Active-Investors
    report count patches with [pcolor = 55 and (any? turtles-here) ]
end

to-report Potential-Investors
  report count turtles
end

to-report Invested-Parcels
  report count patches with [pcolor = 55]
end

to-report Multiple-Investors
  report count patches with [pcolor = 55
and
(count investors-on neighbors > 1)]
end




;
; sweep-test
;
; this is an automated parameter sweeping test
; it runs num-tests interations of the various configurations
; and prints results to the console
;
;Least Favorable
;  set growth-capacity 8
;  set investment-limit-radius 1
;  set num-turtles 25
;  set favorability-threshold 2
;  set favorability-need 4
;  set level-of-competition 1

;Reasonable Scenario
;  set growth-capacity 2
;  set investment-limit-radius 1
;  set num-turtles 25
;  set favorability-threshold 1
;  set favorability-need 2
;  set level-of-competition 2

;Most Favorable
;  set growth-capacity 0
;  set investment-limit-radius 5
;  set num-turtles 700
;  set favorability-threshold 0
;  set favorability-need 0
;  set level-of-competition 9

to sweep-test
  ;
  ; setup the configuration
  ;
;;  set growth-capacity 1
;;  set investment-limit-radius 5
;;  set num-turtles 700
;;  set favorability-threshold 0
;;  set favorability-need 0
;;  set level-of-competition 9


  let num-tests 10
  let i 0

  set i 0
  while [i <= 10]
    [
      setup
      print (Invested-parcels)
      set i (i + 1)
    ]
end

to sweep-test-turtles
  ;
  ; setup the configuration
  ;
  set growth-capacity 3
  set investment-limit-radius 3
  set favorability-threshold 1
  set favorability-need 2
  set level-of-competition 5
  set num-turtles 25

  let num-tests 25
  let i 0

  set i 0
  while [i <= 175]
    [
      setup
      print (word "Invested Parcels, " "Multiple Investors, " "Active Investors, " "Potential Investors, "
        Invested-parcels ", " Multiple-Investors ", " Active-Investors ", " Potential-Investors ", " num-turtles ", " i ", " num-tests)
      set i (i + 1)
      if i = (num-tests) [set num-turtles (50)]
      if i = (num-tests + 50) [set num-turtles (100)]
      if i = (num-tests + 75) [set num-turtles (200)]
      if i = (num-tests + 100) [set num-turtles (300)]
      if i = (num-tests + 125) [set num-turtles (700)]
    ]
end

to sweep-test-turtles-10
  ;
  ; setup the configuration
  ;
  set growth-capacity 3
  set investment-limit-radius 5
  set favorability-threshold 2
  set favorability-need 4
  set level-of-competition 2
  set num-turtles 25

  let num-tests 10
  let i 0

  set i 0
  while [i <= 60]
    [
      setup
      print (word "Invested Parcels, " "Multiple Investors, " "Active Investors, " "Potential Investors, "
        Invested-parcels ", " Multiple-Investors ", " Active-Investors ", " Potential-Investors ", " num-turtles ", " i ", " num-tests)
      set i (i + 1)
      if i = (num-tests) [set num-turtles (50)]
      if i = (num-tests + 10) [set num-turtles (100)]
      if i = (num-tests + 20) [set num-turtles (200)]
      if i = (num-tests + 30) [set num-turtles (300)]
      if i = (num-tests + 40) [set num-turtles (700)]
    ]
end

to sweep-test-growth-capacity
  ;
  ; setup the configuration
  ;
  set growth-capacity 8
  set investment-limit-radius 2
  set num-turtles 300
  set favorability-threshold 1
  set favorability-need 2
  set level-of-competition 2

  let num-tests 25
  let i 0

  set i 0
  while [i <= 175]
    [
      setup
      print (word "Invested Parcels, " "Multiple Investors, " "Active Investors, " "Potential Investors, "
        Invested-parcels ", " Multiple-Investors ", " Active-Investors ", " Potential-Investors ", " growth-capacity ", " i ", " num-tests)
      set i (i + 1)
      if i = (num-tests) [set growth-capacity (5)]
      if i = (num-tests + 50) [set growth-capacity (4)]
      if i = (num-tests + 75) [set growth-capacity (3)]
      if i = (num-tests + 100) [set growth-capacity (2)]
      if i = (num-tests + 125) [set growth-capacity (1)]
    ]
end

to sweep-test-investment-radius
  ;
  ; setup the configuration
  ;
  set growth-capacity 0
  set investment-limit-radius 5
  set num-turtles 700
  set favorability-threshold 0
  set favorability-need 0
  set level-of-competition 9

  let num-tests 25
  let i 0

  set i 0
  while [i <= 150]
    [
      setup
      print (word "Invested Parcels, " "Multiple Investors, " "Active Investors, " "Potential Investors, "
        Invested-parcels ", " Multiple-Investors ", " Active-Investors ", " Potential-Investors ", " investment-limit-radius ", " i ", " num-tests)
      set i (i + 1)
      if i = (num-tests) [set investment-limit-radius (4)]
      if i = (num-tests + 50) [set investment-limit-radius (3)]
      if i = (num-tests + 75) [set investment-limit-radius (2)]
      if i = (num-tests + 100) [set investment-limit-radius (1)]
    ]
end

to sweep-test-favorability-threshold
  ;
  ; setup the configuration
  ;
  set growth-capacity 0
  set investment-limit-radius 5
  set num-turtles 700
  set favorability-threshold 0
  set favorability-need 0
  set level-of-competition 9

  let num-tests 25
  let i 0

  set i 0
  while [i <= 100]
    [
      setup
      print (word "Invested Parcels, " "Multiple Investors, " "Active Investors, " "Potential Investors, "
        Invested-parcels ", " Multiple-Investors ", " Active-Investors ", " Potential-Investors ", " favorability-threshold ", " i ", " num-tests)
      set i (i + 1)
      if i = (num-tests) [set favorability-threshold (1)]
      if i = (num-tests + 50) [set favorability-threshold (2)]
    ]
end

to sweep-test-favorability-need
  ;
  ; setup the configuration
  ;
  set growth-capacity 0
  set investment-limit-radius 5
  set num-turtles 700
  set favorability-threshold 0
  set favorability-need 0
  set level-of-competition 9

  let num-tests 25
  let i 0

  set i 0
  while [i <= 150]
    [
      setup
      print (word "Invested Parcels, " "Multiple Investors, " "Active Investors, " "Potential Investors, "
        Invested-parcels ", " Multiple-Investors ", " Active-Investors ", " Potential-Investors ", " favorability-need ", " i ", " num-tests)
      set i (i + 1)
      if i = (num-tests) [set favorability-need (1)]
      if i = (num-tests + 50) [set favorability-need (2)]
      if i = (num-tests + 75) [set favorability-need (3)]
      if i = (num-tests + 100) [set favorability-need (4)]
    ]
end

to sweep-test-level-of-competition
  ;
  ; setup the configuration
  ;
  set growth-capacity 0
  set investment-limit-radius 5
  set num-turtles 700
  set favorability-threshold 0
  set favorability-need 0
  set level-of-competition 9

  let num-tests 25
  let i 0

  set i 0
  while [i <= 175]
    [
      setup
      print (word "Invested Parcels, " "Multiple Investors, " "Active Investors, " "Potential Investors, "
        Invested-parcels ", " Multiple-Investors ", " Active-Investors ", " Potential-Investors ", " level-of-competition ", " i ", " num-tests)
      set i (i + 1)
      if i = (num-tests) [set level-of-competition (5)]
      if i = (num-tests + 50) [set level-of-competition (4)]
      if i = (num-tests + 75) [set level-of-competition (3)]
      if i = (num-tests + 100) [set level-of-competition (2)]
      if i = (num-tests + 125) [set level-of-competition (1)]
    ]
end
