Leonardi Model 1

extensions [table]

breed [people person]
breed [expectations expectation]
breed [technologies technology]


people-own [usage understanding influencer persistence]
expectations-own [feature strength]
technologies-own [affordances]


directed-link-breed [holds hold]

to setup
  ca


  ;; If auto-total-people is on, make sure the number of people expecting a, b and both doesn't exceed
  ;; the total number set.
  ;; Populate the rest of the world (up to the total number set) with people with no expectations.

  ifelse auto-total-people != "off" and #-expecting-a + #-expecting-b + #-expecting-both > auto-total-people
  [ user-message (word "There are too many people. Turn auto-total off, or reduce the number of people expecting a, b or both.")]
  [ if auto-total-people != "off"
    [ set #-no-expectations auto-total-people - (#-expecting-a + #-expecting-b + #-expecting-both) ]


  ;; create the total number of people who will be in the model
  ;; distribute them randomly around the world
  ;; format their size and shape
  ;; set their usage blank
  ;; format their color to reflect their usage
  ;; give each of them a blank table that will hold their expectations about the technology

  create-people total-#
  [ setxy random-pxcor random-pycor
    set shape "person"
    set size 1.6
    set usage []
    color-code usage .8
    set understanding table:make ]


  ;; for the number of people expecting only a, pick people with blank tables, and set their understanding of feature a to 1
  ask n-of #-expecting-a people with [ table:length understanding < 1 ]
  [ table:put understanding "a" 1 ]

  ;; for the number of people expecting only b, pick people with blank tables, and set their understanding of feature b to 1
  ask n-of #-expecting-b people with [ table:length understanding < 1 ]
  [ table:put understanding "b" 1 ]

  ;; for the number of people expecting a and b, pick people with blank tables, and set their understanding of
  ;; features a and b to 1
  ask n-of #-expecting-both people with [ table:length understanding < 1 ]
  [ table:put understanding "a" 1
    table:put understanding "b" 1 ]


  ;;  build a network of expectations to provide a visual representation of each person's table of understanding
  ask people
  [ update-expectations

    ;; if limited persistence is on, give people a persistence of 3
    ;; if it's off, give people a persistence that is extremely high
    ifelse limited-persistence
    [ set persistence 3 ]
    [ set persistence 1000 ] ]

  ;; format the network of expectations
  ask expectations
  [ format-expectations ]



  ;; set up the technology
  adopt-technology

  reset-ticks ]
end

to update-expectations
  ;; ask people whose table of understandings doesn't match the visual representation of their expectations
  ask people with [table:length understanding != count out-hold-neighbors]

  ;; create a blank slate
  [ ask out-hold-neighbors
    [ die ]

  ;; build the network of expectations up from the understanding table
  let instructions table:keys understanding
  while [instructions != []]
  [ hatch-expectations 1
    [ create-hold-from myself
      ask my-in-holds [hide-link]
      set feature first instructions
      set strength [table:get understanding first instructions] of myself
      set instructions but-first instructions  ] ] ]

  ask expectations
  [ format-expectations ]
end

to format-expectations

  ;; make expectations color, shape and placement reflect what they indicate

  if strength > 0
  [ show-turtle
    set shape "circle"
    set size .5 ]

  if strength < 0
  [ show-turtle
    set shape "x"
    set size .6 ]

  if strength = 0
  [hide-turtle]


  if feature = "a"
  [ setxy ( [ xcor ] of one-of in-hold-neighbors - .5) ( [ ycor ] of one-of in-hold-neighbors + .5)  ]
  if feature = "b"
  [ setxy ( [ xcor ] of one-of in-hold-neighbors + .5) ( [ ycor ] of one-of in-hold-neighbors + .5) ]

  color-code feature 1.5
end

to adopt-technology

create-technologies 1
  [ set shape "box"
    set size 3

    ;; create a blank table that will hold affordances
    set affordances table:make

    ;; fill in the table from the features selected by the user
    let instructions (sentence technology-affordances)
    while [instructions != [] ]
  [ table:put affordances first instructions 1
    set instructions but-first instructions ]

  color-code (table:keys affordances) -2.5]
end


;; color code expectations, usage and affordances to  provide a visual indication of whether they match.

to color-code [thing number]

;; I tried to let the number (i.e. the amount of color change) be set within this procedure, but couldn't get it to work.
;; When the procedure was called by something that didn't hold one of the possible "things" it would
;; stop during the if statements and return an error message. Not sure why it wouldn't just return false and keep going...
;; But anyway, I relented and made the number I want each element's color adjusted by its own input, that I just list
;; when I call the procedure.
;; It's still much more parsimonious this way than having entirely separate procedures to color code expectations,
;; usage, and affordances which is what I used to have...

;let number 1
;if thing = usage
;[set number .8]
;if thing = (table:keys affordances)
;[set number -2.5]
;if thing = feature
;[set number 1.5]


  if member? "a" thing and not member? "b" thing
    [ set color blue + number ]
  if member? "b" thing and not member? "a" thing
    [ set color yellow + number ]
  if member? "a" thing and member? "b" thing
    [ set color green + number]
  if not member? "a" thing and not member? "b" thing
    [ set color gray + number ]
end

to go

  ;; stop conditions
  if all? people [persistence = 0]
    [ stop ]
  if ticks > 99 and (all? people [usage = []]
    or all? people [usage = ["a"]]
    or all? people [usage = ["b"]]
    or all? people [usage = ["a" "b"] or usage = ["b" "a"]])
    [ stop ]

  ;; running the model
  ask people
  [ move
    interact
    update-expectations ]

  tick
end

to move
let path random-normal 0 30
    rt path
    fd 1
    ask out-hold-neighbors
    [ rt path
      fd 1 ]
end

to interact

  set influencer nobody

  if persistence > 0

  ;; if I am near the technology or a person, pick one of those entities to influence me
  [ let potential-influencers (turtle-set technologies in-radius 3 other people in-radius 1)
    ;show potential-influencers
    set influencer one-of potential-influencers
    ;show influencer

    ;; if I am being influenced by a person (social interaction), then learn from their expectations
    if is-person? influencer
    [ learn-from ([understanding] of influencer) ]

    ;; if I am being influenced by the technology (material interaction), then if I have some understanding of
    ;; what the technology is for I will try to use it for that.
    ;; otherwise I will learn from the technology
    if is-technology? influencer
    [ ifelse table:length understanding > 0
      [ use-technology ]
      [ learn-from ([affordances] of influencer) ]
      ;; increment my persistence down
      set persistence persistence - 1 ] ]
end

to learn-from [source]

  ;; if the influencer has any features to learn from,
  ;; pick one to be the insight I learn
  if table:length source > 0
  [ let insight one-of table:keys source

    ;; if that feature is new to me, put the insight into my table of understandings with the same value
    ;; that my influencer has for that feature
    if not table:has-key? understanding insight
    [ table:put understanding insight table:get source insight ] ]
end

to use-technology

;; if I have any positive expectations, pick one of those to be the way I try to use the technology
if any? out-hold-neighbors with [strength > 0]
[ let use [feature] of one-of out-hold-neighbors with [ strength > 0 ]

;; Note: this is the only time I use the expectations breed for more than just visualization. I tried
;; several ways of doing this without appealing to the expectations, but none of them worked. Can't ask
;; about values in a table directly (only keys), can't flatten a table to a non-nested list using sentence
;; (not sure why)... I couldn't think of any other reasonably parsimonious way, using just the tables,
;; that I could pick a feature with a positive value. I wanted to be consistent about either using the
;; expectations turtles for functionality or not. I found them awkward to use for some of the more central
;; interactional procedures--in particular I wanted to create learning procedures that would be "symmetric"
;; (ie work the same) with both people and technology, so I wanted a way to store expectations and
;; affordances the same way for both people and technology...plus it felt strange for expectations to be
;; "held" by people, but not be a directly accessible property of those people, so on balance I decided to
;; switch to using tables. But in this case, I just couldn't figure out a way to do what I needed
;; with tables. I think the functionality should be the same, just a bit less elegant to switch.

;; if the feature I'm trying to use is one of the technology's affordances, then put that feature into my usage
;; if not, set my expectation for that feature negative (and ask my expectation network to adjust accordingly)
;; and remove it from my usage
  ifelse table:has-key? [affordances] of influencer use
[ set usage lput use usage
  set usage remove-duplicates usage
  color-code usage .8 ]
[ table:put understanding use -1
  ask out-hold-neighbors with [feature = use ]
  [ set strength [table:get understanding use] of myself ]
  set usage remove use usage ] ]
end

to-report total-#
report #-expecting-a + #-expecting-b + #-expecting-both + #-no-expectations
end
