Integrating NetLogo and Java tutorial

extensions [diffusion]

globals [
  grid ;; Java object with a type defined by the diffusion extension
  java-loop?
]

patches-own [
  value ;; the more advanced Java code depends on this being variable #5
]

;; code for SETUP button

to setup
  clear-all

  set java-loop? false

  ;; use extension reporter to set up a "clone" of the patch grid
  set grid (diffusion:init-grid world-width world-height min-pxcor min-pycor)

  ;; set up initial values in both patches and grid
  ask patches [
    set value (random-float 9.9)
    if (not java-loop?) [ diffusion:set-grid-cell grid pxcor pycor value ]
    set-patch-color
  ]

  if (java-loop?) [ diffusion:copy-patches-to-grid grid patches ]

  ;; show text dump of the grid
  show grid

  ;; some turtles
  crt 10 [
    setxy random-xcor random-ycor
    set shape "person"
    set color sky
    set size 4
  ]

  reset-ticks
end

;; code for GO button

to go
  ;; perform several computation steps within the grid
  repeat 10 [
    diffusion:diffusion-step grid 0.01
  ]

  ;; copy modified grid data to the patches
  if-else (java-loop?) [ copy-grid-to-patches2 ] [ copy-grid-to-patches1 ]

  ;; have the turtles interact with the modified patches
  ask turtles [
    uphill value
  ]

  tick
end

;; utility method (called twice) to set a patch color from a value

to set-patch-color
  set pcolor (30 + value)
end

;; copy grid data to the patches: loop within NetLogo

to copy-grid-to-patches1
  ask patches [
    set value (diffusion:get-grid-cell grid pxcor pycor)
    set-patch-color
  ]
end

;; copy grid data to the patches: loop within Java

to copy-grid-to-patches2
  diffusion:copy-grid-to-patches grid patches
  ask patches [
    set-patch-color
  ]
end
