Crazy Vectors

extensions [bitmap qtj]
breed [vectors vector]
breed [balls ball]
vectors-own [vector-size head-turtle]
balls-own [speed energy last-collision last-vector]
patches-own [cluster previous-color]
globals [ circle-patches line-patches wall-patches circle-clusters line-clusters max-tick-delta background-color]

to reset-image
  clear-all
  set background-color 9.9
  ask patches [set cluster nobody set pcolor background-color]
  set-default-shape balls "circle 2"
  set-default-shape vectors "circle 2"
  reset-ticks
end

to reset-background
  ask patches [set pcolor background-color]
end

to import-image
  let myimage "images/random-balls.png"
  if image-file = "random-balls" [set myimage "images/random-balls.png"]
  if image-file = "force-field" [set myimage "images/force-field.png"]
  if image-file = "current" [set myimage "images/current.png"]
  import-pcolors myimage
end

to normalize-colors
 set circle-patches patches with [(pcolor > 11 and pcolor < 18) or (pcolor > 121 and pcolor < 128) or (pcolor > 131 and pcolor < 138)]
 set line-patches patches with [shade-of? blue pcolor = true]
 set wall-patches patches with [pcolor >= 0 and pcolor <= 1]
 reset-background
 ask circle-patches [set pcolor 15]
 ask line-patches [set pcolor 105]
 ask wall-patches [set pcolor 0]
end

to detect-clusters
  let drawing-patches (patch-set circle-patches line-patches)
  if any? drawing-patches with [cluster = nobody] [
    let counter 1
    set circle-clusters []
    set line-clusters []
    loop [
      let seed one-of drawing-patches with [cluster = nobody]
      if seed = nobody [ stop ]
      ask seed
      [ set cluster counter
        grow-cluster
        ifelse pcolor = red [set circle-clusters lput counter circle-clusters]
           [set line-clusters lput counter line-clusters]
        ]
    set counter counter + 1
    ]
  ]
end

to grow-cluster  ;; patch procedure
  ;ask neighbors with [(cluster = nobody) and
  ask patches in-radius 2 with [(cluster = nobody) and
    ;ask neighbors4 with [(cluster = nobody) and
    (pcolor = [pcolor] of myself)]
  [ set cluster [cluster] of myself
    grow-cluster ]
end

to convert-to-turtles
  reset-background
  ask wall-patches [set pcolor 0]
  foreach circle-clusters [
    if count (patches with [cluster = ?]) > 5 [generate-circles patches with [cluster = ?]]
  ]

  foreach line-clusters [
    if count (patches with [cluster = ?]) > 5 [generate-lines patches with [cluster = ?] ?]
  ]
end

to generate-circles [shape-patch-set]
  let max-x-point max [pxcor] of shape-patch-set
  let min-x-point min [pxcor] of shape-patch-set
  let max-y-point max [pycor] of shape-patch-set
  let min-y-point min [pycor] of shape-patch-set

  let radius (max-x-point - min-x-point + max-y-point - min-y-point) / 4 ; find approximate radius for the circle
  let center-x ((max-x-point + min-x-point) / 2)
  let center-y ((max-y-point + min-y-point) / 2)

  let center-patch patch center-x center-y ;center of circle

  let std-to-center (standard-deviation ([distance center-patch] of shape-patch-set) / (mean [distance center-patch] of shape-patch-set))

  if std-to-center < std-to-center-threshold [
    create-balls 1 [
      setxy center-x center-y
      set size (radius * 2)
      set color red
      set speed 0
      set heading 0
      set last-vector -1 * vector-refresh
      ]
  ]
end

to generate-lines [shape-patch-set cluster_]
  let max-x-point max [pxcor] of shape-patch-set
  let min-x-point min [pxcor] of shape-patch-set
  let max-y-point max [pycor] of shape-patch-set
  let min-y-point min [pycor] of shape-patch-set

  let center-patch patch ((max-x-point + min-x-point) / 2) ((max-y-point + min-y-point) / 2)

  let end-patch1 (max-one-of shape-patch-set [distance center-patch]) ;end-patches are the tip and end patches

  let end-patch2 (max-one-of shape-patch-set [distance end-patch1])

  let head-patch max-one-of (patch-set end-patch1 end-patch2) [count shape-patch-set in-radius 3] ;with the arrow shape there are more patches

  let bottom-patch min-one-of (patch-set end-patch1 end-patch2) [count shape-patch-set in-radius 3] ;the tip-patch has the arrow head

  let new-vector nobody

    create-vectors 1 [
      setxy [pxcor] of bottom-patch [pycor]  of bottom-patch
      set size 2
      set color blue
      set vector-size sqrt ((max-x-point - min-x-point) ^ 2 + (max-y-point - min-y-point) ^ 2)
      set new-vector self
    ]
      ask head-patch [sprout 1 [
        set shape "default"
        set size 5
        set color blue
        set heading (180 + towards new-vector)
        create-link-from new-vector [set shape "vector" set color blue]
        ask new-vector [set head-turtle myself set heading [heading] of myself]
    ]
      ]
end

;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;Below is the physics simulator. The code above is used for recognizing shapes and converting them into turtles
;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;
;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;

to setup
 ; set max-tick-delta 2;0.1073
  ask balls [set speed 0 set heading 0]
  ;set tick-delta 1
  reset-ticks
end

to go
  ask balls [move]
  tick-advance tick-delta
end

to move
    let radius size / 2
    ifelse pen-down? = true [pendown][penup]
    let vector-range (radius) + 5

    let is-vector? (any? vectors in-radius vector-range and (ticks - last-vector > vector-refresh))
    let is-friction? (friction > 0)

    if is-vector? or gravity > 0 [

      let x-speed speed * cos heading
      let y-speed speed * sin heading

      if is-vector? [
        ask vectors in-radius vector-range [

          set x-speed (x-speed + (vector-size * (cos heading) * tick-delta) / [size] of myself)
          set y-speed (y-speed + (vector-size * (sin heading) * tick-delta) / [size] of myself)

          if remove-vectors-on-hit? = true [ask head-turtle [die] die]


        ]
         set last-vector ticks
      ]

      if gravity > 0 [ set x-speed (x-speed - 0.0001 * gravity) ]
      set speed sqrt (x-speed ^ 2 + y-speed ^ 2)
      if not (x-speed = 0 and y-speed = 0) [set heading atan  y-speed x-speed]

    ]
      if friction > 0 [set speed speed * (1 - friction)]



;;;BOUNCE
  if (not horizontal-wrap? and abs xcor + radius >= max-pxcor) or ([pcolor] of patch (xcor + radius) ycor = 0) or ([pcolor] of patch (xcor - radius) ycor = 0) [set heading (-1 * heading) ]

  if (not vertical-wrap? and abs ycor + radius >= max-pycor) or ([pcolor] of patch xcor (ycor + radius) = 0) or ([pcolor] of patch xcor (ycor - radius) = 0) [set heading (180 - heading) ]


  fd speed * tick-delta
end
